Control Panel Switch Functions - Adphibian/AX 651 Multi EDS

Key Switch (A)
Main power switch.
Detergent System (B)
This switch controls the AXP system.
• Pressing and releasing this switch while the solution system is active will toggle the AXP system on and off.
• The AXP Indicator (D1) informs the operator when the detergent bottle is low. Pressing and holding the Detergent
System switch for two seconds after the AXP bottle has been refilled will reset the AXP Indicator on the display to
show full.
• Holding the Detergent System switch and the Solution Pre-spray Switch (C) at the same time for two seconds will
switch the machine into the purge mode.
Solution Pre-spray Switch (C)
If the scrub system is off and the machine is in the extract mode, pressing this switch will cause the machine to enter
pre-spray mode. The following will occur:
• The scrub system will be enabled with the system configured for pre-spray mode, and the scrub deck will be lowered
while the extraction/vacuum shoes stay up in the locked position.
• The solution system will be enabled for pre-spray mode.
• The detergent system will be enabled for pre-spray mode.
• The travel speed will be limited to a fast pre-spray mode speed setting.
• As soon as the throttle is moved from the neutral position the scrub brushes will start turning. If the direction is
forward, the solution and detergent flow will start. If the direction is reverse, the solution and detergent flow will be
stopped.
• This will indicate the scrub system is activated in the fast pre-spray mode.
• The Scrub ON Switch (J), Solution Pre-spray Switch (C) and the Detergent System switch (B) will be green if the
scrub system is on and the fast pre-spray mode has been selected. The indicators will be off if the scrub system is
off. The indicators will be yellow if the maintenance mode has been selected but the throttle is in neutral.
• Pressing the Scrub On Switch (J) in this mode causes the machine to enter a heavy pre-spray mode. In this mode
the machine moves slower and more solution is sprayed on the carpet. The Heavy Pre-spray Mode indicator (D8)
will change to indicate the scrub system is in heavy pre-spray mode.
If the pre-spray mode is active, pressing this switch will cause the following will occur:
• The scrub brushes will turn off and the scrub deck will rise to the up position.
• The solution flow and detergent flow will be stopped.
• The travel speed limit will return to the transport speed setting.
• The Pre-spray Mode Indicators (D7 and D8) will indicate that the nozzles are turned off and the deck is in the raised
position.
• The indicator in the Scrub OFF Switch (H) will be green if the scrub system is off and ready to be activated. The
indicator will be off if the scrub system has been activated. If the scrub system has been turned off and the scrub
deck is not up yet the indicator will be red. If there is a fault in the scrub system this indicator will flash red.
18 - Form No. 56043116 - Adphibian™/AX 651 Multi EDS/AquaPLUS™
