• The vacuum system will be enabled. Both vacuum motors will be activated when the machine is in an extract mode.
• The solution system will be enabled for the LIFT mode.
• The travel speed will be limited to the LIFT mode speed setting.
• As soon as the throttle is moved from the neutral position, the scrub brushes will start turning and the vacuum will
turn on. If the direction is forward, the solution flow will start. If the direction is reverse, the solution flow will be
stopped.
• The LIFT Low Moisture Extract Mode Indicator (D5) will indicate that the scrub system is activated in the LIFT mode.
If the machine is an extract mode and the scrub system is in the LIFT mode, pressing this switch will cause the machine
to enter the restoration extract mode. The following will occur:
• The scrub system will be enabled with the system configured for the restoration mode
• The vacuum system will be enabled. Both vacuum motors will be activated when the machine is an extract mode.
• The solution system will be enabled for the restoration mode
• The travel speed will be limited to the restoration mode speed setting
• As soon as the throttle is moved from the neutral position, the scrub brushes will start turning and the vacuum will
turn on. If the direction is forward, the solution flow will start. If the direction is reverse, the solution flow will be
stopped.
• The Restoration Extract Mode Indicator (D6) will indicate that the scrub system is activated in the restoration mode.
If the machine is in the hard floor scrub mode, and the scrub system is off or set to the heavy pressure setting, pressing
this switch will cause the machine to enter light pressure scrubbing mode. The following will occur:
• The scrub system will be enabled with the system configured for light scrub pressure. If the scrub system was off, the
scrub deck will be lowered. The extraction/vacuum shoes will remain locked in the raised position and the operator
will lower the squeegee manually.
• The vacuum system will be enabled. Only one vacuum motor will be activated when the machine is in the hard floor
scrub mode.
• The solution system will be enabled. In hard floor mode the machine has only one solution setting. The Solution
Active Indicator (D15) will show a full gauge and the "maintenance" nozzle is activated.
• The detergent system will be enabled.
• The travel speed will be variable from 20% to 100%.
• As soon as the throttle is moved from the neutral position, the scrub brushes will start turning and the vacuum will
turn on. If the direction is forward, the solution flow will start. If the direction is reverse, the solution flow will be
stopped.
• The Light Scrub Pressure Indicator (D14) will indicate the light scrub pressure setting by showing the scrub pressure
icon with a half-full gauge next to it.
If the machine is in hard floor scrub mode and the scrub system is set to the light pressure setting, pressing this switch
will cause the machine to enter the heavy pressure scrubbing mode. The following will occur:
• The scrub system will be enabled with the system configured for heavy scrub pressure.
• The vacuum system will be enabled. Only one vacuum motor will be activated when the machine is in the hard floor
scrub mode.
• The solution system will be enabled. In the hard floor mode the machine has only one solution setting. The Solution
Active Indicator (D15) will show a full gauge and the "maintenance" nozzle is activated.
