Vacuum Shoe Maintenance
Check the vacuum shoes daily. Remove any built-up string, hair or carpet fibers. To remove:
1. Press the red Scrub OFF Switch (H). Turn the master Key Switch (A) off.
2. Remove the Debris Hopper (29).
Note: Remove the left side shoe first to allow clearance for the right side shoe to slide out.
3. See Figure 14. Disconnect the Vacuum Hoses from the Vacuum Shoes (10).
4. Pull up on the Ring (42) and hold up while pulling the Vacuum Shoe forward, then out of the machine.
5. Repeat steps 3 and 4 for the right side Vacuum Shoe.
6. Follow the above steps in reverse order to reassemble.
Figure 14
52 - Form No. 56043116 - Adphibian™/AX 651 Multi EDS/AquaPLUS™
