Use and maintenance
Operating guidelines AS710R/AS850R
Disconnect battery charger
and store the cable in the
storage compartment located
under the seat.
Adjust squeegee angle
and blade pressure for
optimal water pick-up by
turning the adjustment
knob on the support.
Use the Switch to change direction,
F= forward and R= reverse.
Switch brush motor button on.
September 2019
Fill the solution tank with
fresh water and add low foam
detergent according to needs.
Insert the operator key and
start the machine.
Lower brush with the foot pedal.
Push the drive pedal to start cleaning.
Solution level indicator is on
the side of the tank showing
current level.
Adjust the maximum
speed with the speed
adjustment dial.
Lower the squeegee with the handle.
Install the squeegee and fi x it
by using the two knobs.
Adjust water level by pressing
+ or – button.
Advertisement
Related Manuals for Nilfisk-Advance Viper AS710R
Summary of Contents for Nilfisk-Advance Viper AS710R
- Page 1 Use and maintenance Operating guidelines AS710R/AS850R Disconnect battery charger Fill the solution tank with Solution level indicator is on Install the squeegee and fi x it and store the cable in the fresh water and add low foam the side of the tank showing by using the two knobs.
- Page 2 Maintenance Operating guidelines AS710R/AS850R Turn OFF the machine using Empty and clean the recovery tank and fl oat system. Empty solution tank. the key. Check and clean fi lter (weekly). Press the brush click off button and inspect Take the squeegee off, check and clean Hang the squeegee on the machine to dry.
