Speed Control Programming Options

Following is a list of the speed control parameters that can be adjusted using a Curtis hand held programmers:
• M1 MAX SPEED – Transport/Scrub speed maximum limit (% of full throttle)
• M2 MAX SPEED – Not applicable
• M1 MIN SPEED – Transport/Scrub speed maximum limit with the speed limit pot in minimum position (% of full
throttle limited by speed limit pot)
• M2 MIN SPEED – Not applicable
• M1 REVERSE MAX SPEED – Reverse Transport/Scrub speed maximum limit (% of full throttle)
• M2 REVERSE MAX SPEED – Not applicable
• REVERSE MIN SPEED – Transport/Scrub speed maximum limit with the speed limit pot in minimum position (% of
full throttle limited by speed limit pot)
• THROTTLE AUTOCAL – Used for calibration of the throttle assembly

Installation Checkout for the Curtis Speed Controller

Warning!
The 1210 controller is inherently a high-power device. When working around any battery powered vehicle, appropriate
safety precautions should be taken. These include, but are not limited to:
• Proper training,
• Wearing eye protection,
• Avoiding loose clothing and jewelry, and,
• Using insulated wrenches.
After installing a controller and before operating the vehicle, carefully complete the following checkout procedure. If you
find a problem during the checkout, refer to the Diagnostics section of this chapter for further information.
The installation checkout can be conducted with or without the handheld programmer. The checkout procedure is
easier with a programmer. Otherwise, observe the Status LED for codes (located on operator panel wand indicator
light). The part number of the handheld programmer is 56409441.
Warning!
• Put the vehicle up on blocks to get the drive wheel off the ground before beginning these tests.
• Turn the Key Switch off and make sure the throttle is in neutral.
• Do not stand, or allow anyone else to stand directly in front of or behind the vehicle during the tests.
1. Remove electrical panel to access controller, then observe LED status light on touch pad operator panel wand
indicator light. If a programmer is available, connect it to the programmer plug-in port.
2. Turn the Key Switch on. The programmer should "power up" with an initial display. If neither happens, check for
continuity in the Key Switch circuit and controller ground.
3. If you are using a programmer, put it into the diagnostic mode by pressing the
should indicate No Faults Found.
82 - Form No. 56043116 - Adphibian™/AX 651 Multi EDS/AquaPLUS™
key. The display
DIAGNOSTICS
