CSvision

4. CSvision
4.1.

Setup CSvision

The button Setup [Menu: Device\ Device Setup] opens a window for the setting of all sensor parameters.
The dialog window is separated into 5 categories:
▪ Signal processing
▪ Output
▪ I/O Pins
▪ Display
▪ Advanced settings
▪ Video
Setting of Ratio Mode, Emissivity/ Slope, Max Attenuation and Post
processing
Setting of Output 1 and Output 2
Setting the In- and Outputs
Display main value and Backlight/ Alarm setting
RS485/Modbus settings, Calibration
Setting of video signals
CSvision
-
83
