CTratio
2.
CTratio
2.1.
Sensor Setup CTratio
The button Setup [Menu: Device\ Device Setup] opens a window for the setting of all sensor parameters.
The dialog window is separated into 4 categories:
▪ Signal processing
▪ Output
▪ I/O Pins
▪ Display
▪ Advanced settings
Setting of Emissivity/ Slope and Post processing
Setting of Output 1 and Output 2
Setting the In- and Outputs
Display main value and Backlight/ Alarm setting
RS485 Multidrop address, Optical Set, Calibration
CTratio
-
27
