optris CompactPlus Connect Operator's Manual page 15

Basics
Overview of Digital Display
Notation
T Process temperature
Proc
T Ratio temperature
Ratio
T 1-channel temperature
1
T 2-channel temperature
2
T Actual temperature of ratio
ActRatio
T Actual temperature of channel 1
TAct1
T Actual temperature of channel 2
TAct2
Attenuation Signal attenuation
T / T Head temperature
Det Int
T Box temperature
Box
T Average temperatur
Avg
Note
The available temperatures depend on the connected device type
Description
With signal processing, including averaging
Without signal processing, including averaging
Without signal processing, including averaging
Without signal processing, including averaging
Without signal processing, without averaging
Without signal processing, without averaging
Without signal processing, without averaging
Signal attenuation
Temperature value of detector
Temperature of electronic box
Without signal processing, including averaging
-
15
