3.1.3. Post Processing

Under Post Processing you can set the
averaging and hold mode.
Averaging: In this mode an arithmetic algorithm
will be performed to smoothen the signal. The
Averaging Time is the time constant. This function
can be combined with all other post processing
functions.
The minimum adjustable average time is for the CT
4M model 1ms (0,001s). On this model values
below 0,1 s can be increased/ decreased only by
values of the power series of 2 (0,002, 0,004,
0,008, 0,016, 0,032, ...).
Under the Averaging Mode you can choose
between Normal and Adaptive. With Adaptive, a
dynamic adjustment of the averaging process is
performed for steep
Averaging).
The following post-processing functions are available:
Off
Averaging
signal edges (Smart
If Off is activated, no post processing will happen (T
In this mode an arithmetic algorithm will be performed to smoothen the
signal. The Avg. time is the time constant. This function can be combined
with all other post processing functions. The minimum adjustable average
-
= T ).
Proc Avg
