3.2.4. Relays

When using the optional relay interface, T
T can be selected as source.
Box
Under Threshold the threshold value for triggering
the alarm is defined.
Selecting Open/Closed under Mode defines the
output as High or Low alarm.
Difference mode: When activated, no absolute
value is used for the alarm threshold, but the
difference between process temperature and
ambient temperature (TProc-TAmb).
, T or
Proc Int
-
