Belt-driven 4-position 25mm filter wheel (special):
LB4-W (without shutter). Requires a LAMBDA 10-B circuit board only (no keyboard or
display), programmed with special firmware.

1.3.2.1 Mechanical Description

The basic components of the filter wheel mechanical assembly are shown in following figures.
The only components that are to be removed by the user are the drop-in or slide-in filter
holders and the plug in the loading port. At no time should the user remove the cover plate
from the wheel housing.
1. 10-position wheel (removed from motor hub)
2. Installed filter cup
3. Wheel housing
4. Cover plate (removed from wheel housing
5. Stepper motor
6. Drop-in filter holder (Figure 1-1) or slide-in filter holder (Figure 1-2)
7. Mounting ears
8. Optical port
9. Loading port (plug installed)
10. Shutter housing

1.3.3 Filters

The LAMBDA 10-B Controller can be used with a range of filter wheels. Most of these wheels
accept both 25 mm and 1-inch diameter filters. When larger filters are required, a wheel is
available that accepts 32 mm diameter filters.
Filter wheels designed for use with 1 inch or 25 mm filters will accept filters with a thickness
that does not exceed the following dimensions:
▪
mm (0.18 in.) for Slide-in filter holders
•
5.38 mm (0.21 in.) for Drop-in filter holders
•
9 mm (0.35 in.) for Filter cups
Filter wheels designed for use with 32 mm filters will accept filters with a thickness that does
not exceed the following dimensions:
• 9 mm (0.35 in.) for Filter cups
Instructions for installing filters into the filter wheel can be found in the FILTER WHEEL
chapter of this manual. Sutter Instrument Company does not supply filters but filters
conforming to the above specifications can be purchased from any filter manufacturer.

1.3.4 Slide-in or Drop-in Filter Holders

Many users prefer having extra Slide-in or Drop-in filter holders for more convenient
replacement of these "fixed" filters. Only use filter holders made by Sutter Instrument
Company in the LAMBDA 10-B Filter Wheel. Extra filter holders for one-inch wheels are
readily available from Sutter Instrument Company or their distributors and are listed as
