NOTE: All commands indicated with "*" are not available in early versions of the LAMBDA 10-B (those prior to
Revision D).
The following paragraphs describe the special commands in more detail.

5.4.1 Status

The Status command is used to return information about the filter wheel state (if installed)
and the state of one or two shutters (if, and as, installed). The following tables describe the
type of data and information returned by the Status command. The first table shows the data
returned when the LAMBDA 10-B is in the "Filter Wheel/Shutter" configuration, whereas
the second table shows the status data returned when in the "2 Shutter" configuration.
Table 5-9. "Get Status" command return data in a "Wheel & Shutter" configuration.
Byte Label
Offset
0 Command echo
1 Wheel A status
2 Shutter
open/closed state
3 SmartShutter
mode
(1 or 2 bytes)
(4)*
4 or Return data
(5)* terminator
* NOTE: The length of the status data structure when the LAMBDA 10-B is in the "Wheel & Shutter" configuration is 5 or 6
bytes depending on whether a SmartShutter is connected and, if connected, what mode is it in. If no SmartShutter is installed
or if the SmartShutter Mode is not Neutral Density, then the length of the data is 5 and ends with the return data terminator at
Offset 4. If a SmartShutter is connected and its mode is set to Neutral Density, then the level of neutral density (1-144
microsteps) is present at Offset 4 and the return data terminator is moved to Offset 5.
Byte Value
Dec. Hex. Binary
204 CC 11001100
0xxxxxxx
x000xxxx
-
x111xxxx
xxxx0000
-
xxxx1001
10 0A 00001010
170 AA 10101010
171 AB 10101011
172 AC 10101100
219 DB 11011011
220 DC 11011100
221 DD 10111011
222 DE 10111100
1 00000001
01
– -
–
144 10010000
90
13 0D 00001101
LAMBDA 10-B OPERATION MANUAL – REV. 1.20Q (20230227)
Description
The Status command byte code
echoed back.
WHEEL A SELECT: 1 bit.(Bit 7)
Pattern: 0xxxxxx (always zero)
SPEED: 3 bits. (Bits 6, 5, & 4)
Bit Pattern: x000xxx – x111xxxx
POSITION: 4 bits (Bits 3, 2, 1, &
0)
Bit Pattern: xxxx0000 – xxxx1001
Either no filter wheel is installed
or there is an error on the 15-pin
wheel port.
Open
Open is conditional
Closed
Indicates no SmartShutter or a
Vincent shutter is connected.
Fast Mode
Soft Mode
Neutral Density Mode
Number of microsteps (1 – 144) for
neutral density mode.
NOTE: The number of neutral
density microsteps is present at
this byte offset only if Shutter A
Mode is set to Neutral Density
(Offset 3 = 222 (0xDE)).
ASCII CR (carriage return).
55
Bit Values
Dec./–
Binary
Hex
0 0
0 000
- -
7 111
0 0000
- -
9 1001
