Open Shutter A; Open Shutter A Conditionally; Close Shutter A; Open Shutter B - Sutter Instrument LAMBDA 10-B Operation Manual

Command Tx/- Ver. Total
Delay/-
Rx
Soft-mode Tx All
Shutter
Rx All
Neutral Tx All
Density-mode
Shutter
Rx All
The following paragraphs describe the shutter commands in more detail.

5.3.1 Open Shutter A

Sets Shutter A to the open state.

5.3.2 Open Shutter A Conditionally

Configures Shutter A to open while the filter wheel is stopped. The shutter will close each
time the filter wheel moves and then will open again at the end of the move.

5.3.3 Close Shutter A

Sets Shutter B to the closed state.

5.3.4 Open Shutter B

Sets Shutter B to the open state.

5.3.5 Open Shutter B Conditionally

Same as the "Open Shutter A Conditionally" command, but applicable to Shutter B. NOTE:
This command is valid only with models of the Lambda 10 series that support both a pair of
filter wheels and a pair of shutters installed at the same time. This command is not valid in
the LAMBDA 10-B.

5.3.6 Close Shutter B

Sets Shutter B to the closed state.

5.3.7 Fast-Mode Shutter

Sets the mode of the specified shutter to FAST (
SmartShutter" configuration, a second byte following the command byte indicates Shutter A
(1) or B (2).
Byte Value
Bytes Offset
Dec. Hex.
(Len.)
2 0 221 DD
1 1 01
- -
3 02
1 0 13 0D
3 0 222 DE
1 1 01
- -
3 03
2 1 01
- -
144 90
1 0 13 0D
LAMBDA 10-B OPERATION MANUAL – REV. 1.20Q (20230227)
Alt- Ctrl- ASCII
key- char def./-
Binary
pad # char.
1110 1101 0221
0000 0001 0001
– -
0000 0011 0003
0000 1101 <CR>
1110 1110 0222
0000 0001 0001
– -
0000 0011 0003
0000 0001 0001
– -
1001 0000 0144
0000 1101 <CR>
Smart
Shutter only). In the "Dual-
53
Description
Sets soft mode
(SmartShutter only).
2 nd byte indicates Shutter A
(1) or B (2).
Completion indicator
Sets neutral-density mode
(SmartShutter only).
2 n byte indicates Shutter A
(1) or B (2).
3 rd byte contains 1 - 144
indicating microsteps.
Completion indicator
