68
http://www.sutter.com/SOFTWARE/SI_CDM_vx_xx_xx.zip
and the installation instructions at
http://www.sutter.com/SOFTWARE/CDM_driver_Install_Guide.pdf
Extract the contents of the device driver into a folder and disk drive of your choosing. To
install the device driver, please refer to the "CDM_driver_Install_Guide.pdf" downloaded
separately.

7.4 Installing the USB interface for non-Windows systems

The LAMBDA 10-B can be connected via USB interface to computers that are not running
Windows. However, limited support and information is provided for them. For the Linux and
Macintosh operating systems, please visit the following web sites for more information.
1. Linux drivers and tools:
http://ftdi-usb-sio.sourceforge.net/
2. Apple Macintosh drivers, tools, and information:
http://www.ftdichip.com/FTMacDriver.htm

7.5 Verifying USB Communication between Remote Computer and LAMBDA 10-B

Once the LAMBDA 10-B has been connected to the remote computer with the USB cable and
the remote computer has had the necessary device drivers installed, you will probably want
to test and verify that the remote computer is, in fact, communicating correctly with the
LAMBDA 10-B over its USB connection. Probably the most expedient method for doing this
testing is to install and run on the remote computer the USB Test and Demo program for the
Lambda 10-series (a Windows program). This program is called "USBTest", and once
installed, can be used to determine if the remote computer is able to communicate with the
LAMBDA 10-B as a USB device. The USBTest program is provided on a 3.5-inch HD floppy
diskette or CD-ROM, shipped with the LAMBDA 10-B or it can be downloaded from Sutter
Instrument Co.'s web site (www.sutter.com). The files that make up the distribution of the
USBTest program include the Setup program. Simply run this setup program to install
USBTest on your system (Windows-based systems only.
The USB Test & Demo program can be downloaded from Sutter Instrument's web site using
the following link:
https://www.sutter.com/SOFTWARE/Lambda_Test.zip
NOTE: The USB version of the program is for use only when the LAMBDA 10-B is connected
to your computer over the USB interface and either the standard device driver is installed or
the CDM device driver is installed with VCP disabled.
If VCP is enabled, then the COM Port version of the program should be used instead.
LAMBDA 10-B OPERATION MANUAL – REV. 1.20Q (20230227)
