One filter wheel with built-in shutter (SmartShutter or UNIBLITZ
One standalone SmartShutter
2. Two standalone SmartShutters (no filter wheel)
Note that the operation of the LAMBDA 10-B, its manual-control menu structure, and
remote-control command structure (serial and USB), all change between the two basic
configurations listed previously.

1.3.1.2 Filter Wheel and Shutter Configurations NOT Supported

The following combinations of filter wheels and shutters are not supported by the LAMBDA
10-B.
• More than one filter wheel.
•
One standalone filter wheel and more than one shutter.
•
More than one Uniblitz shutter.
• One Uniblitz shutter and one SmartShutter.
•
More than two standalone SmartShutters (no filter wheel)

1.3.2 Filter Wheels

When a LAMBDA 10-B Filter Wheel system is purchased, its configuration may include one
filter wheel, with or without a shutter. If the LAMBDA 10-B system is purchased with a 10-
position 25mm (1-inch) filter wheel, you may wish to exchange the filter wheel with a 10-
position 32mm or a 5-position 50mm filter wheel. If the filter wheel being replaced is a 10-
position 32mm filter wheel equipped with a 35mm shutter (UNIBLITZ® or SmartShutter),
then LAMBDA 10-B controller must be modified by Sutter Instrument Co. before said filter
wheel with shutter is connected. If the 32mm filter wheel is not equipped with a shutter, or if
installing a 50mm filter wheel, then no modification to the LAMBDA 10-B controller is
needed. Note that you must only use filter wheels manufactured by Sutter Instrument
Company. All filter wheel options are listed in the Sutter Instrument catalogue and in the
following list.
10-position, 25mm filter wheels:
LB10-NW (without shutter)
LB10-NWIQ (with 25mm SmartShutter)
LB10-NWS (with UNIBLITZ® shutter)
LB10-NWE (without shutter and set up for emission)
4-position, 25mm filter wheels:
LB10-WHS4 (without shutter)
LB10-WHS4IQ (with SmartShutter)
LB10-WHS4E (without shutter and set up for emission)
10-position 32mm filter wheels:
LB10-W32 (without shutter)
LB10-NW32IQ (with 35mm SmartShutter)
LB10-W32S (with 35mm UNIBLITZ® shutter)
5-position 50mm filter wheel:
LB10-W50 (without shutter).
1
UNIBLITZ is a registered trademark of Vincent Associates.
