Setting And Activating Options (Papopt); Activation Of Tractors (Autotra) - Dascom Tally T2380 User Manual

User guide
Setting and activating
options (PapOpt)
FFmode PapOpt
Back Next
1 2 3 4

Activation of tractors (AutoTra)

AutoTra AutoASF
Back Next
1 2 3 4
AutoTra=Off *
Set < > Exit
1 2 3 4
For setting the optional automatic sheet feeders (ASFs) and optional
tractors; see
ASFs and/or optional tractors.
Press PapOpt (3) key.
Online
Setup
This parameter only appears if at least one optional tractor is in-
stalled. It regulates the activation of tractors when there is no more
paper left in one of them.
Press AutoTra (2) key.
Online
Setup
Use the < (2) or > (3) key to select the desired setting.
Online Setting Options: Off/T1=T2/T1=T2=T3
Default Setting: Off
Setup
If an optional tractor is not installed, Off is displayed (factory de-
fault). If an optional tractor is installed and the Off parameter is acti-
vated, only the selected tractor is supported (either via the menu or
an ESC sequence). If the selected tractor is out of paper, printing
stops.
If an optional tractor is installed and you select T1=T2 (standard
printer) or T1=T2=T3 (2T model), the printer will load paper from the
other tractor if the selected one is empty.
For the 2T model, the selection priority is T2–T3–T1, i.e. if the se-
lected T2 is out of paper, the printer will first try to load paper from
T3, then from T1. If the selected T3 is empty, the printer will first ad-
dress T1, then T2. If T1 is selected and empty, first T2, then T3 will
be addressed.
Confirm the setting by pressing the Set key (1).
Paperway (page 5). Also regulates the activation of
The Menu
89
