Paper Guiding Bracket; Selecting The Rear Tractor - Dascom Tally T2380 User Manual

2T model
Paper guiding
bracket
Selecting the rear
tractor
Load paper from
Trac3
1 2 3 4
52
Important: It is absolutely necessary to mount the paper guid-
STOP
ing bracket when using the rear tractor. It serves to protect the
mains and interface cables from being damaged by the paper
in the rear tractor.
The rear tractor can be selected either from an application program,
the paper path quick selection or via the setup menu. This chapter
describes the paper path quick selection; for information on how to
make the setting in the Setup menu, refer to Setup mode.
Make sure that the printer is in offline mode; press the Online key,
if necessary.
Press the Park key (1). If fanfold paper is loaded in the printer, it is
transported to the tear position. Tear paper will be displayed. Then
press any key.
Press the Trac3 (4) key to select the rear tractor.
If you do not make a selection within 5 seconds, the
menu is closed.
The printer returns to offline mode.
Online The display alternates between the basic menu and:
Setup
Hook the paper guiding bracket at the bottom of
the printer as shown in the figure and then raise
it until it clicks into place by exerting gentle
pressure.
User guide
