Interface specifications

Parallel interface
Type of data transmission
Transmission rate
Signal status
Connection cable
Voltage supply of external devices on
pin 18
Interface connections
Ethernet interface
Transmission rate
Supported protocoles
Network print protocoles
IP address designation
Connection cable
Network print management protocoles
Capacity of data buffer
bidirectional
8-bit parallel interface (Centronics compatible) IEEE-1284;
Nibble mode
Max. 30 KHz
Low: 0.0 V to +0.4 V
High: +2.4 V to +5.0 V
Material: AWG 28 at least
Length: up to 2.0 m
Twisted-pair cable with double-shield,
acc. IEEE Std 1284 – 1294
U = +5 V ±10%
I = 0.5 A
max
Printer side:Amphenol 57-40360, 36-pin (or compatible)
Cable side:Amphenol 57-30360, 25-pin (or compatible)
Onboard 10/100BaseT Ethernet-RJ45 with 2 LEDs
100 Mbps / Full Duplex
TCP/IP
LPR/LPD, RAW Port
DHCP, BootP and manually over the control panel
RJ45; Cat 5e, 6
HTTP, HTML, SNMP
8 MB
Specifications
