7.1.3 Details of Service Mode

iPF650 / iPF655
This section provides details of the Service mode menu.
a) DISPLAY
Displays and prints the printer information.
1) PRINF INF
Prints adjustment values in the User menu, [DISPLAY] and [COUNTER] parameters on A4-size or lager paper.
When a roll media is used, the layout is optimized according to the media width.
2) SYSTEM
Displays the printer information shown below.
Display
S/N
TYPE
LF TYPE
TMP
RH
SIZE LF
SIZE CR
AFTER
INST.
3) HEAD
Displays the following EEPROM information of the printhead.
4) INK
Displays the numbers of days passed since installation of the following ink tanks.
Display
BK
MBK
MBK2
C
M
Y
5) WARNING
Displays the warning history (up to 20 events). The newest event has the smallest history number.
6) ERROR
Displays the error history (up to 20 events). The newest event has the smallest history number.
Serial number of printer
Type setting on main controller PCB
* iPF655/650 is represented by 24".
Feed roller type: 0 or 1
Ambient temperature
Ambient humidity
Detected size of loaded media (feed direction)
0 is always detected for the roll media.
Detected size of loaded media (carriage scan direction)
Number of days since initial installation
Display
S/N Serial number of printhead
LOT Lot number of printhead
Number of days passed since the BK ink tank was installed
Number of days passed since the MBK ink tank was installed
Number of days passed since the MBK ink tank was installed
Number of days passed since the C ink tank was installed
Number of days passed since the M ink tank was installed
Number of days passed since the Y ink tank was installed
T-7-8
Description
T-7-9
Description
T-7-10
Description
Chapter 7
Unit
-
-
-
centigrade
degrees
%
mm/inch
mm/inch
Days
Unit
Days
Days
Days
Days
Days
Days
0023-5341
7-9
