Canon ImagePROGRAF iPF650 Series Service Manual page 267

Display massage Code*
Hardware error. 03130031-2F2B
03130031-2F2B
Turn off printer, wait,
then turn on again.
Printhead error 03800200-2802
Open top cover and
replace the printhead.
Printhead error 03800300-2801
Open top cover and
replace the right
printhead.
Printhead error 03800400-2803
Open top cover and
replace the right
printhead.
Hardware error. 03800500-2F2F
03800500-2F2F
Turn off printer, wait,
then turn on again.
Hardware error. 03800500-2F30
03800500-2F30
Turn off printer, wait,
then turn on again.
Ink tank is empty. 03810104-2500
Press OK and replace ink
tank.
Ink tank is empty. 03810101-2501
Press OK and replace ink
tank.
Ink tank is empty. 03810102-2502
Press OK and replace ink
tank.
Ink tank is empty. 03810103-2503
Press OK and replace ink
tank.
Ink tank is empty. 03810106-2506
Press OK and replace ink
tank.
Ink tank is empty. 03810106-2507
Press OK and replace ink
tank.
Ink insufficient. 03810204-2580
Press OK and replace ink
tank.
Ink insufficient. 03810201-2581
Press OK and replace ink
tank.
Ink insufficient. 03810202-2582
Press OK and replace ink
tank.
Ink insufficient. 03810203-2583
Press OK and replace ink
tank.
Ink insufficient. 03810206-2586
Press OK and replace ink
tank.
Ink insufficient. 03810204-2590
Press OK and replace ink
tank.
Ink insufficient. 03810201-2591
Press OK and replace ink
tank.
Ink insufficient. 03810202-2592
Press OK and replace ink
tank.
Ink insufficient. 03810203-2593
Press OK and replace ink
tank.
Ink insufficient. 03810206-2596
Press OK and replace ink
tank.
Ink tank error. 03830204-2540
Press OK and replace ink
tank.
Condition detected
LF operation failure
Invalid printhead installed
Printhead DI compensation failure
Printhead EEPROM error
Non-discharging error
Non-discharging position adjustment error
Bk ink tank empty
Y ink tank empty
M ink tank empty
C ink tank empty
MBk ink tank empty
MBk2 ink tank empty
Low on the Bk ink tank (as during cleaning)
Low on the Y ink tank (as during cleaning)
Low on the M ink tank (as during cleaning)
Low on the C ink tank (as during cleaning)
Low on the MBk ink tank (as during cleaning)
Low on the Bk ink tank (during pre-printing checks) Replace with a fully replenished Bk ink tank
Low on the Y ink tank (during pre-printing checks)
Low on the M ink tank (during pre-printing checks)
Low on the C ink tank (during pre-printing checks)
Low on the MBk ink tank (during pre-printing checks) Replace with a fully replenished MBk ink tank
Bk ink tank ID error
Action
Check to see if paper has not jammed.
Check the feed motor and feed roller.
Replace printhead
Replace printhead
Replace printhead
Identify the head management sensor unit
Replace the head management sensor unit
Replace the printhead
Identify the head management sensor unit
Replace the head management sensor unit
Replace the printhead
Renew the Bk ink tank
Renew the Y ink tank
Renew the M ink tank
Renew the C ink tank
Renew the MBk ink tank
Renew the MBk ink tank
Replace with a fully replenished Bk ink tank
Replace with a fully replenished Y ink tank
Replace with a fully replenished M ink tank
Replace with a fully replenished C ink tank
Replace with a fully replenished MBk ink tank
Replace with a fully replenished Y ink tank
Replace with a fully replenished M ink tank
Replace with a fully replenished C ink tank
Replace with a valid Bk ink tank
Chapter 8
8-7
