Canon ImagePROGRAF iPF650 Series Service Manual page 47

[Set./Adj. Menu]
Setting Item
[Test Print] [Nozzle Check]
[Status Print]
[Interface Print]
[GL2 Set Print]
[Paper Details]
[Print Job Log]
[Menu Map]
[Color Palette]
[Adjust [Head Posi.
Printer] Adj.]
[Head Inc. Adj.]
[Feed Priority] [Adj. Priority] [Automatic]
[Adj. Fine Feed]
[Maintenance] [Head Cleaning]
[Nozzle Check]
[Replace P.head]
[Repl. maint cart]
Print a nozzle check pattern.
Print the printer information.
Print the interface settings.
Print the GL2 settings.
Prints the paper settings set with [Paper Details].
Print print job information such as paper type, size, and ink consumption. Ink consumption is
the approximate amount of ink used to print one sheet.
Print the menu list.
Print the GL2 color list.
[Auto(Standard)] Print and read a test pattern for the automatic adjustment of Printhead alignment relative to the
printing direction.
[Auto(Advanced)] Print and read a test pattern for the automatic adjustment of Printhead alignment relative to the
nozzle and printing direction.
[Manual] Print a test pattern for adjustment of Printhead alignment relative to the printing direction. Enter
the adjustment value manually based on the resulting pattern.
Print an adjustment pattern for adjusting the inclination of the printhead.
Set the priority feed precision. Normally select [Automatic]. Select [Print Quality] to print at
high quality. Select [Print Quality] to reduce horizontal streaks. Select [Print Length] to
[Print Quality]
accurately control the feed amount. However, selecting [Print Length] may cause colors to
[Print Length]
become slightly uneven in the carriage scan direction.
[Adj. Quality] [Auto(Genuin Set when using paper described in the paper reference guide.
ePpr)] A pattern to adjust the paper feed amount is printed, and the feed amount is automatically
adjusted from the printed result.
[Auto(OtherPa Set when using paper not described in the paper reference guide.
per)] A pattern to adjust the paper feed amount is printed, and the feed amount is automatically
adjusted from the printed result.
This takes longer than [Auto (GenuinePpr)] to print and consumes more ink.
[Manual] Select for paper that cannot be adjusted by [Auto(GenuinePpr)] or [Auto(OtherPaper)], such as
highly transparent paper.
Print a pattern to adjust the paper feed amount according to the type of paper.
[Adjust [AdjustmentPr Print a test pattern for adjustment relative to paper stretching or shrinkage, after which you can
Length] int]-[A:High]/ enter the amount of adjustment.
[B:Standard/
Draft]
[Change Displayed when [Print Length] is selected as [Adj. Priority] for [Feed Priority].
Settings]- Adjust the expansion rate of the currently loaded paper.
[A:High]/ Enter the result adjusted with [AdjustmentPrint] or the difference with your own measurement
[B:Standard/ in %.
Draft] Increase the adjustment value to increase the feed amount for paper that tends to expand, and
reduce it for paper that tends to shrink.
Displayed when [Automatic] or [Print Quality] is selected as [Adj. Priority] for [Feed Priority].
Manually adjust the paper feed amount while printing.
Specify Printhead cleaning options.
Choose Head Cleaning A if printing is faint, oddly colored, or contains foreign substances.
Choose Head Cleaning B if no ink is printed at all, or if printing is not improved by Head
Cleaning A.
Print a nozzle check pattern.
Not displayed during a warning message that the remaining Maintenance Cartridge capacity is
low.
When replacing the Printhead, choose Yes and follow the instructions on the screen.
When exchanging the maintenance cartridge, choose Yes and follow the instructions on the
screen.
T-1-16
Description/Instructions
