[1] Accessory pocket
Store the printer accessories.
[2] Basket
Ejected printouts are collected in this basket.
[3] Lockable caster
This caster can be locked.
When relocating the printer, be sure to unlock all four casters. Moving the printer with the casters locked can damage the floor.
[4] Switching stopper
Pull out this stopper when using the basket at the extended position.
[5] Paper guide
This guide is used to lead the ejected printout to the basket.
[1]
[2]
[5]
[3]
F-1-25
Chapter 1
[4]
1-17
