Canon ImagePROGRAF iPF650 Series Service Manual page 265

Display massage Code*
Paper size not detected. 03010000-200C
Lift the release lever and
reload the paper.
Cannot adjust eccentric. 03863000-2822
Press Online to clear the
error.
Sheet printing is selected. 03860002-2E02
Press Load/Eject and load
sheets.
Roll printing is selected, 03860002-2E0A
but sheets are loaded.
Press OK, remove the
sheets, and load a roll.
Roll printing is selected. 03060A00-2E00
Press Load/Eject and load
a roll.
No Roll Feed Unit. 03060A00-2E0E
Turn printer off and
install roll feed unit.
The roll is empty. 03060A00-2E1B
Lift the release lever and
replace the roll.
Wrong paper feed slot for 03061000-2E15
this paper type.
Press Load/Eject and
reload the paper.
Manual printing is 03860001-2E0C
selected, but a roll is
loaded.
Press Load/Eject and
remove the roll.
Hardware error. 03130031-2E23
03130031-2E23
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F14
03130031-2E14
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F16
03130031-2E16
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F17
03130031-2E17
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F20
03130031-2E20
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F22
03130031-2E22
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F23
03130031-2E23
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F25
03130031-2E25
Turn off printer, wait,
then turn on again.
Hardware error. 03130031-2F26
03130031-2E26
Turn off printer, wait,
then turn on again.
Condition detected
Roll media loading size detection failure
Eccentricity correction disabled
Data with a cut sheet specification has been received
but no cut sheets are loaded.
Data with a roll media specification has been received
when a cut sheet tray is loaded.
Data with a roll media specification has been received
but no roll media are loaded.
Roll media unit not installed
Roll media end
Paper type mismatch
Data with a cut sheet specification has been received
when roll media are loaded.
Cutter unit failure
Writing to the ASIC register disabled
Mist fan error
Suction fan lock detection error
Purge motor cam position error
Pump travel timeout
Purge motor error
Pump inoperable
Unable to detect the carriage motor home position
Carriage inoperable
Action
Reload the roll media.
Check to see if paper has not jammed.
Load cut sheets at the paper tray port.
Replace with roll media.
Load roll media.
Install the roll media unit.
Renew the supply of roll media.
Check the type of paper that can be fed and reload the
paper.
Load cut sheets at the paper tray port.
Check the cutter unit.
Replace the main controller PCB
Check the mist fan.
Check the suction fan.
Check the purge unit.
Check the purge unit.
Check the purge unit.
Check the carriage unit. Check the linear encoder for
smears.
Check the carriage unit and surrounding parts.
Chapter 8
8-5
