Canon ImagePROGRAF iPF650 Series Service Manual page 168

Chapter 4
4.3.11 Waste Ink Collection Unit
iPF650 / iPF655
When disassembling the waste ink collection unit, pay attention to the ink leaking from the disassembled parts. Put the parts of the disassembled waste ink collection
unit in a plastic bag or the like with care given to the ink leaking from the portion [A] enclosed in a circle.
The service parts packing box may include a plastic bag for packing replacement parts. Use it for putting consumable parts of the waste ink collection unit.
No
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[1] Mist Fan
4-34
[1]
[4]
[2]
Name
Mist Fan
Mist Exhaust Duct
Platen Suction Fan
Platen Exhaust Duct
Head Management Sensor
Maintenance Cartridge
Ink Tank Unit Waste Ink Tray
Purge Unit Waste Ink Tray
Front Duct
[A]
[8]
[3]
[7]
[5]
[6]
[9]
[7]
F-4-77
T-4-1
Q'ty Part number Consumables
1 QM3-5854 Yes
1 QM3-5853 Yes
1 QM3-5905
1 QM3-5805 Yes
1 QM3-5956 Yes
1 -
1 -
1 -
1 -
F-4-78
Service Mode
(PARTS xx)
Mi-1
Mi-1
WF-2
HMa-1
0023-5290
