Canon ImagePROGRAF iPF650 Series Service Manual page 226

Chapter 7
OUTPUT 4
OUTPUT 5
OUTPUT 6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
MEMO:
- Display is all "?" if "GAP CALIB" is not performed.
- If the value exceeds 1000, 999 is displayed.
7-16
O U T P U T 4
X X X X X X X X X
21 21 21 22 22 22 23 23 23
O U T P U T 5
X X X X X X X X X
26 26 26 27 27 27 28 28 28
O U T P U T 6
X X X X X X X X X
31 31 31 32 32 32 33 33 33
Display
position
Media edge (diffuse reflection) media output (including outside light)
Media edge (diffuse reflection) outside light output (when LED is OFF)
Media edge (diffuse reflection) platen output (excluding outside light)
Media edge (diffuse reflection) gain
Media edge (diffuse reflection) current value (Unit: X10mA)
Media edge (regular reflection) media output (including outside light)
Media edge (regular reflection) outside light output (when LED is OFF)
Media edge (regular reflection) platen output (excluding outside light)
Media edge (regular reflection) gain
Media edge (regular reflection) current value (Unit: X10mA)
GAP1 media output (including outside light)
GAP1 outside light output (when LED is OFF)
GAP1 platen output (excluding outside light)
GAP1 gain
GAP1 current value (Unit: X10mA)
GAP2 media output (including outside light)
GAP2 outside light output (when LED is OFF)
GAP2 platen output (excluding outside light)
GAP2 gain
GAP2 current value (Unit: X10mA)
Density (red) media output (including outside light)
Density (red) outside light output (when LED is OFF)
Density (red) platen output (excluding outside light)
Density (red) gain
Density (red) current value (Unit: X10mA)
Density (green) media output
Density (green) outside light output (including outside light)
Density (green) platen output (excluding outside light)
Density (green) gain
Density (green) current value (Unit: X10mA)
Density (blue) media output (including outside light)
Density (blue) outside light output (when LED is OFF)
Density (blue) platen output (excluding outside light)
Density (blue) gain
Density (blue) current value (Unit: X10mA)
X X X X X X
24 24 24 25 25 25
F-7-11
X X X X X X
29 29 29 30 30 30
F-7-12
X X X X X X
34 34 34 35 35 35
F-7-13
T-7-18
Description
