Chapter 1
Type of media
Supported thickness
Media size (Roll media)
Media size (Cut sheet)
Printable area (Roll media)
Printable area (Cut sheet)
Printing recommendation area
(Roll media)
Printing recommendation area
(Cut sheet)
Memory
Hard disk drive
Firmware
Interface
Operation panel
Printhead/Ink Tank type
Printhead
Ink tank
Detection functions (Cover
system)
Detection functions (Ink passage
system)
1-10
Roll Media:
Plain Paper, Plain Paper (High Quality), Plain Paper (High Grade), All
Plain Paper_Conserve MBK, Premium Plain Paper, Coated Paper,
Heavyweight Coated Paper, Premium Matte Paper, Premium Glossy
Paper 200, Premium Semi-Glossy Paper 200, Premium Glossy Paper
280, Premium Semi-Glossy Paper 280, Back Light Film, Economy Bond
Paper, Universal Bond Paper, Matte Coated Paper 170gsm, Premium RC
Photo Luster, Durable Backlit Film, High Resolution Coated Paper,
Matte Coated Paper 90gsm, Glossy Photographic Paper 190gsm, Glossy
Photographic Paper 240gsm, Satin Photographic Paper 240gsm, Glossy
Photographic Paper 270gsm, Satin Photographic Paper 270gsm, HW
Glossy Photo Paper, HW Satin Photo Paper, Commercial Proofing
Paper, Standard Paper1569B 80g, Standard Paper1570B 90g, Matt
Coated Paper 9171, Matt Coated Paper 7215, Matt Coated Paper 140g,
Opaque Paper White, Hi Res Graphic Paper, Hi Res Barrier Paper, Photo
Realistic Paper 210g, Photo paper Pearl 260g, Glossy Proofing Paper
195g, Semiglossy Proofing Paper 195g, Semiglossy Proofing Paper 255g
Cut Paper:
Plain Paper, Plain Paper (High Quality), Plain Paper (High Grade), All
Plain Paper_Conserve MBK, Premium Plain Paper, Coated Paper,
Premiun Matte Paper, Premium Glossy Paper 280, Premium Semi-
Glossy Paper 280, High Resolution Paper, Matte Photo Paper, Glossy
Photo Paper GP-501, Photo Paper Plus Glossy 2, Photo Paper Pro
Platium, Photo Paper Plus Semi-Gloss, Universal Bond Paper, Premium
RC Photo Luster, High Resolution Coated Paper, Matt Coated Paper
7215, Matt Coated Paper 140g
0.07mm to 0.8mm
Width: 254.0mm (10") to 609.6mm (24")
Length: 203.2mm (8") to 18m (709") *1
Outer diameter of roll :150mm or less
*1: The maximum amount of length may vary by the using operating
system or the applications.
Width: 203.2mm (8") to 609.6mm (24")
Length: 279.4mm (11") to 1600mm (63") *1
*1: The maximum amount of length may vary by the using operating
system or the applications.
Internal area, excluding a 3-mm top, bottom and left and right margins.
Borderless printing: 0 mm from the leading edge, trailing edge, and left
and right edges.
* The printable area may vary with each type of paper media used.
Width of media allowing borderless printing:
24"(609.6mm), A1(594.0mm), B2(515.0mm),
A2(420.0mm), 14"(355.6mm), 300mm, A3(297.0mm), B4(257.0mm),
10"(254mm)
Internal area, excluding a 3-mm top margin, a 23-mm bottom margin and
3-mm left and right margins.
* The printable area may vary with each type of paper media used.
Internal area, excluding a 20-mm top margin, a 5-mm bottom margin and
5-mm left and right margins.
Internal area, excluding a 20-mm top margin, a 23-mm bottom margin
and 5-mm left and right margins.
256MB
Increase of memory: none
80GB (2.5inch, 5400rpm)
Flash ROM (update from USB or Ethernet)
- Printer description language
GARO (Graphic Arts language with Raster Operation), HP-GL/2, HP-
RTL
USB2.0 Hi-Speed
Network (10Base-T/100Base-TX/1000Base-T)
LCD (160 X 128 dots), 13 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean, Russianand
and Japanese
Printhead and separate ink tanks
PF-04
Structure: Integrated six-color assembly
Number of nozzles: 5,120 for MBK, 2,560 for other each color
PFI-102 MBK/BK/C/Y
PFI-104 M
Capacity: 130 ml per color (Ink tanks supplied with the printer contain
90 ml pf each color.)
Upper cover open/closed detection: Yes
Ink tank cover open/closed detection: Yes
Ink tank presence/absence detection: Yes
Remaining ink level detection (dot count and electrode): Yes
Maintenance cartridge presence/absence detection: Yes
Used ink tank full detection: Yes
Ink supply Valve open/closed detection: Yes
Ink passage Valve open/closed detection: Yes
17"(431.8mm),
