Chapter 8

8.3 Error Table

8.3.1 Errors

iPF650 / iPF655
* Codes represent the numbers that are displayed in DISPLAY in service mode.
If the same message is displayed when the printer is turned off, then back on, take action as recommended in the Action column.
Display massage
PHead needs cleaning. 03800500-280C
Press Online to clear
error.
Paper size not detected. 03010000-200C
Lift the release lever and
reload the paper.
Leading edge detection 03010000-200D
error.
Lift the release lever and
align leading edge with
orange line.
Paper size not detected. 03010000-2017
Lift the release lever and
reload the paper.
Paper size not detected. 03010000-2018
Lift the release lever and
reload the paper.
Cannot adjust printhead. 03863000-2820
Press Online to clear the
error and readjust
printhead.
Cannot adjust printhead. 03863000-2821
Press Online to clear the
error and readjust
printhead.
Cannot print as specified. 03010000-2E1F
Lift the release lever and
replace paper with A4/
LTR (vertical) or larger.
Cannot print as specified. 03010000-2E1F
Lift the release lever and
replace paper with A3/
Ledger (vertical) or
larger.
Cannot print as specified. 03010000-2E1F
Lift the release lever and
replace roll with 10 in.
wide or larger roll.
Cannot detect papr 03010000-2E25
Remove paper and press
Load/Eject.
Cannot feed paper 03010000-2E27
Lift the release lever and
reload paper.
This paper cannot be 03010000-200E
used.
Check supported paper
sizes.
This paper cannot be 03010000-200F
used.
Check supported paper
sizes.
Use another paper. 03010000-2F33
Press Online to clear the
error.
Paper loaded askew. 03016000-2010
Lift the release lever.
Paper size not detected. 03010000-200A
Reload paper.
Paper jam. 03010000-2E27
Press Load/Eject and
reload the paper.
8-4
Code* Condition detected
Printhead found to have many non-discharging
nozzles during a non-discharging inspection (printing
paused)
Unable to detect the leading end of paper
Unable to detect the trailing end of cut sheet
Paper (right) edge detection error
Paper (left) edge detection error
Printhead registration unadjustable
LF unadjustable
Undersized paper loaded for internal printing (A4 or
larger)
Undersized paper loaded for internal printing (A3 or
larger)
Undersized paper loaded for internal printing (roll
media)
Paper jam while feeding/ejecting/printing
Paper jam during feeding/printing/ejection
Undersized paper (cut sheets/roll media)
Oversized paper (cut sheets/roll media)
Unadjustable because of transparent media
Skew
Unable to detect the paper width (Paper loaded at an
improper position)
Paper jam during feeding/printing/ejection
T-8-3
Clean the printhead. Identify the nozzles in a nozzle check
pattern. Replace the printhead.
Check the leading end of paper. Reload the paper.
Check the sheet length. Check to see if paper has not
jammed.
Check the right edge of paper. Check the paper type.
Check the left edge of paper. Check the paper type.
Check the paper on which a pattern is printed for smears.
Check the environment for interferences from outside
light.
Clean the printhead.
Check the paper on which a pattern is printed for smears.
Check the environment for interferences from outside
light.
Clean the printhead.
Replace with A4/Letter or any larger-sized paper.
Replace with A3/11"x17" or any larger-sized paper.
Replace with roll media at least 10 inches in width.
Remove the paper jam and reload the paper.
Reload the paper.
Replace with larger-sized paper.
Replace with smaller-sized paper.
Replace with adjustable media.
Correct the skew in the paper and reload it.
Reload the paper
Reload the paper
0023-3206
Action
