Chapter 7
7) JAM
Displays log of jams that have occurred (up to five events). The newest event has the smallest history number.
Indicates the date and time of jam and error code. "0000" is displayed if there is no log.
Press the key to display detail information.
Press the key or key to navigate among detail information display 1 to 4.
Detail information display 1
Detail information display 2
Detail information display 3
Detail information display 4
Display Description
1 Jam type
2 Media
3 Jam timing
4 Media width detection
5 Head height
6 Platen shutter position
7 Cut mode setting
8 Environment
9 Borderless printing setting
10 Print mode
11 Media siz
12 Media name
8) INK CHECK
Displays the history of execution of turning off the remaining ink level detection (by using the refilled ink tank) in the order of C, M, Y, MBK, MBK2 and BK.
0: No execution
1: Executed at least once
7-10
0 1 M M / D D
X X X X - X X X X
F-7-1
J A M 0 1
1 : X X X X X X X X X
1 2 3 4 5 6 7 8 9
F-7-2
J A M 0 1
2 : X X X X X X X X X
10
F-7-3
J A M 0 1
3 : X X X X
11
F-7-4
J A M 0 1
4 : X X X X X X X X
12
F-7-5
T-7-11
1:Carriage error, 2:Jam, 3:Feed failure (delay), 4:Cut failure, 0:Unknown
1:Roll media, 2:Cut sheet, 0:Unknown
1:Feed, 2:Print, 3:Eject, 0:Unknown
1:ON, 2:OFF, 0:Unknown
SL:1.0mm, L:1.3mm, M1:1.8mm, M2:2.0mm, M3:2.2mm, 0:Unknown
1:Fully close, 2:HP side only open, 3:1/4 open, 4:1/2 open, 5:3/4 open, 6:Fully open, 0:Unknown
1:User cut, 2:Eject cut, 3:Auto cut, 0:Unknown
Display Media Information Tool's environment settings A to F according to Temperature/Humidity Detection
Sensor, 0:Unknown
1:Bordered printing, 2:Borderless printing, 0:Unknown
Display print mode, 0:Unknown
Display media size, 0:Unknown
Display media name, 0:Unknown
H H : M M
LCD display contents
