Chapter 2: Jumpers and Connectors
Battery Connector
Connector type: 1x2 2-pin header, 1.25mm pitch
Connector location: J1
1
2
Pin
Settings
1
GND
2
BAT
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
12V Header
Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP4
1
2
Pin
Settings
1
12V
2
GND
19
XPPC 16-200 User Manual
