Nexcom XPPC 16-200 User Manual page 54

Chapter 4: BIOS Setup
Serial Port 2 Configuration
Aptio Setup - AMI
Advanced
Serial Port 2 Configuration
Serial Port
[Enabled]
Device Settings IO=2F8h; IRQ=10;
Version 2.21.1278. Copyright (C) 2021 AMI
Serial Port
Enables or disables the serial COM port.
Device Settings
Displays the IO address and IRQ of the serial COM port.
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
CPU Temperature
Detects and displays the current CPU temperature.
System Temperature
Detects and displays the current system temperature.
Fan1 Speed
Detects and displays the current fan speed.
Vcore
Detects and displays the Vcore voltage
+5V
Detects and displays 5V voltage
40
Aptio Setup - AMI
Advanced
Pc Health Status
CPU Temperature : +45 ºc
System Temperature : +48 ºc
Fan1 Speed : N/A
VCORE : +1.280 V
+5V : +5.068 V
Version 2.21.1278. Copyright (C) 2021 AMI
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
XPPC 16-200 User Manual
