Chapter 4: BIOS Setup
F81804 Super IO Configuration
This section is used to configure the serial ports.
Aptio Setup - AMI
Advanced
F81804 Super IO Configuration
Super IO Chip F81804
Serial Port 1 Configuration
Serial Port 2 Configuration
Version 2.21.1278 Copyright (C) 2021 AMI
Super IO Chip
Displays the Super I/O chip used on the board.
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Serial Port 1 Configuration
Set Parameters of Serial Port
1 (COMA)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Serial Port
Enables or disables the serial COM port.
Device Settings
Displays the IO address and IRQ of the serial COM port.
Onboard Serial Port Mode
Select this to change the serial port mode to RS232, RS422, RS485.
39
Aptio Setup - AMI
Advanced
Serial Port 1 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=3;
Onboard Serial Port 1 Mode [RS232]
Version 2.21.1278. Copyright (C) 2021 AMI
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
