CyberData 011324 Series Operation Manual page 41

Web Page Item
802.3AT Mode
Force 802.3AT Mode (NOT recommended)
Misc Settings
Device Name
Auto-Answer Incoming Calls
Beep on Init
Beep on Page
Two Speakers Connected
RGB Strobe
DTMF Settings
Require Security Code
Security Code
Play Stored Message
Operations Guide
Table 2-10. Device Page Parameters (continued)
Description
This device automatically detects if it is plugged into an 802.3AT (also
known as PoE Plus) power source. 802.3AT provides more power than
older 802.3AT power sources and allows this speaker to play audio at
higher volumes. If you are sure this speaker is connected to an 802.3AT
power source, but it is not being detected correctly, you can override the
automatic settings below.
Enable this option if you are sure this speaker is connected to an 802.3AT
power source, but it is not being detected correctly (not recommended).
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer incoming calls.
When Auto-Answer Incoming Calls is disabled, the device will play a
ring tone (corresponds to Ring Tone on the Audiofiles page) out of the
speaker.
Device will play the user-defined "pagetone" audio file when it boots.
Device will play the user defined "pagetone" audio file before playing a
SIP page.
Specify if one or two speakers are connected to the paging amplifier. If
only one is connected, ensure that it is wired to the first set of terminal
blocks.
Status of optional RGB Strobe.
When selected, the user will be prompted to enter a Security Code
(entered on this page) before being able to execute a page when calling
the device.
Type the Security Code in this field. The Security Code must only use
characters '0-9', '*' and '#'. Enter up to 25 characters.
When selected, the caller will be prompted to select one of nine stored
messages to play through the speaker. Stored messages may be
customized on the Audiofiles page.
Click the Save button to save your configuration settings.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the
web page items. First click on the Toggle Help button, and you will see a
question mark (
mouse pointer to hover over a question mark to see a short description of
a specific web page item.
Click on the Test Relay button to do a relay test.
931971A
Installing the SIP Paging Amplifier
) appear next to some of the web page items. Move the
SIP Paging Amplifier Setup
CyberData Corporation
34
