CyberData 011324 Installation Quick Reference

Dimensions
CLASS II WIRING
3
MIC IN
2
1
5
4
STROBE
3
2
1
SAFETY WARNING!
Please read the owner's manual for proper
installation. Incorrect wiring can lead to
and/or other attached components.
CLASS II WIRING
Mono(+)/Left Spkr (+) - 12
Left Spkr (-) - 11
Right Spkr (+) - 10
Mono(-)/Right Spkr (-) - 9
Line-Out (+) - 8
Line-Out (-) - 7
Line-In (-) - 6
Line-In (+) - 5
Relay COM - 4
Relay NO/NC - 3
Door Sense/Button Common (GND) - 2
Door Sense/Button Contact (+) - 1
www.cyberdata.net
0.326 [8.3]
1.042 [26.5]
Contacting CyberData
Corporate Headquarters
Sales: (831) 373-2601 ext. 334
CyberData Corporation
Support: 831-373-2601 ext. 333
3 Justin Court
Support Website:
Monterey, CA 93940, USA
RMA Department: (831) 373-2601 ext. 136
Phone: 831-373-2601 RMA Email: RMA@CyberData.net
Fax: 831-373-4193 RMA Status: http://support.cyberdata.net/
http://www.cyberdata.net/
Warranty Information:
© 2016, CyberData Corporation, ALL RIGHTS RESERVED 931154D
ø0.172 [ø4.4]
(2 Places)
3.295 [83.7]
Dimensions are in Inches [Millimeter]
http://support.cyberdata.net/
http://support.cyberdata.net/
Quick Reference
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Installation Quick Reference
The IP Endpoint Company
SIP Paging Amplifier
011324
Parameter
IP Addressing
a
IP Address
Web Access Username
Web Access Password
a
Subnet Mask
a
Default Gateway
a. Default if there is not a DHCP server present.
Typical System Installation
Compliant Non-PoE Ethernet Switch
SIP Paging Amplifier
Getting Started
• Download the Operations Guide PDF file from the Documents tab at the following webpage:
http://www.cyberdata.net/voip/011324/
• Create a plan for the locations of your paging amplifiers.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: The SIP Paging Amplifier enclosure is not rated for any AC voltages!
Parts
(1) Assembly
(1) Screw Accessory Kit
(2) Plastic Ribbed Anchors
Quick Reference
Factory Default Setting
DHCP
10.10.10.10
admin
admin
255.0.0.0
10.0.0.1
*See the Operations Guide for more
installation options.
IP-PBX Server
VoIP Phone
(2) #6x1.25" Pan Head
Phillips Sheet Metal Screw
931154D © 2016, CyberData Corporation, ALL RIGHTS RESERVED
