Installation - Direct IP IDIS DC-D1011 Installation Manual

Part 1 – Introduction
GND
Alarm
Out
TYPE 1
In
GND
Audio
Out
TYPE 1
In
GND
Video
CVBS
DC12V +
Power DC12V -
FGND
DC-D1212R receives power via PoE (Power over
Ethernet) and is therefore incompatible with DC12V
power sources.
18
Grounding
Alarm Out (Active Low -
Open Collector Output)
Alarm In
Grounding
Audio Out
Audio In
Grounding
Video Out
Power connection
(Check + and -
markings)
Frame grounding

Installation

Installation of this product does not require the use of
special tools.
For more information on other devices comprising the
overall system, refer to their respective installation
manuals.
Product color and design may vary depending on the
model.
Installation
Shield case is included with
DC-D1122 / DC-D1122V / DC-D1122W /
DC-D1123 / DC-D1123V / DC-D1123W / DC-D1223 /
DC-D1223V / DC-D1223W
• Check the wall or ceiling to see if it needs to be
reinforced. The camera may fall off if the wall or
ceiling is not strong enough to support its weight.
• Install the camera in a shaded area. If the camera is
installed in direct sunlight, it may affect adversely.
DC-D1022W /
only.
