Part 1 – Introduction
• Video Out
– CVBS (Video Out) & GND (Ground): Connect
the cable's signal line and ground line to these
ports and the connector on its opposite end to
a monitor. Use these ports for previewing video
and not monitoring video. Go to Remote Setup
(System > General) and choose a video out signal.
(NTSC or PAL)
• Power
– DC12V +/-: Connect the two wires of the power
adapter to these ports. Be careful not to cross
the + and - wires. Booting will commence once
connected to a power supply.
– FGND (Frame Ground): Used to ground the
device.
DC-D1212 / DC-D1212R
PoE (Power over Ethernet) and is therefore
incompatible with DC12V power sources.
• Network LED
Indicates the network connection status. For more
information, refer to the LED Status Indications. If
the Status LED option under System > General has
not been enabled, this LED will remain turned off
regardless of the network connection status.
16
receives power via
• Network Port
Connect a network cable with an RJ-45 connector to
this port. If using a PoE switch, you can supply power
to the camera using an ethernet cable. For more
information on PoE switch use, refer to the switch
manufacturer's operation manual. You can configure,
manage, and upgrade this camera and monitor its
images from a remote computer over the network.
For more information on network connection setup,
refer to the IDIS Discovery operation manual.
• Power LED
Indicates the system's operating status. For more
information, refer to the LED Status Indications. If
the Status LED option under System > General has
not been enabled, this LED will remain turned off
regardless of the system's operating status.
When inserting an alarm in/out, audio in/out, video
out, or power connector, hold down the button and
push the connector in through the exposed hole.
(Alarm in/out and audio in/out apply to
models only) Release the button and then gently
pull on the wire to ensure a secure connection. To
disconnect, press down on the button again and pull
the wire out.
TYPE 1
