Camera Installation

Waterproof Cable Installation
RJ45 waterproof rubber ring
RJ45 waterproof rubber ring
PoE IN/OUT modular jack
PoE IN/OUT modular jack
RJ45 connector back cover (2)
RJ45 connector back cover (2)
1
1
1
Insert a round rubber ring (silicone rubber) into
2
the PoE IN jack and PoE OUT jack each.
2
3
2
Insert the network cable into the waterproof cap,
rubber bushing, and waterproof cap body in order.
3
4
Network Camera
4
(2)
(2)
RJ45 connector protect cover
(2)
cable waterproof rubber ring (2)
(The waterproof rubber ring is fastened to the connector protect cover.)
RJ45 connector protect cover
(2)
cable waterproof rubber ring (2)
(The waterproof rubber ring is fastened to the connector protect cover.)
3
3
3
3
3
Plug in the network cable.
4
4
4
4
4
Connect the plug terminal to the PoE IN jack and
5
5
PoE OUT jack each.
5
5
6
6
5
Push the waterproof cap body and cap into the
6
PoE IN jack and PoE OUT jack each and rotate
them.
6
6
Lock the waterproof cap into the waterproof cap
body.
