- Page 1 Network Camera Quick Guide DC-D4537RXA DC-D4537HRXA Powered by...
-
Page 2: Safety Precautions
Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read before the Do not overload wall outlets and extension cords as this can result appliance is operated. -
Page 3: Fcc Compliance Statement
FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. -
Page 4: Dome Cover
Warning: This product emits infrared light. Do not look into the IR LED. Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. Some parts may differ depending on the situation. Item Network Camera Quick Guide DC-D4537HRXA... - Page 5 Body DC-D4537HRXA DC-D4537RXA IR LED Network Port Dome Cover Assembly Lens Part Factory Reset Button Alarm I/O, Audio I/O Built-in Microphone SD Memory Card Slot Wall/Ceiling Cable Rubber Installation Hole Power Network Camera...
-
Page 6: Camera Installation
Camera Installation Removing the Dome Cover DC-D4537RXA Turn the dome cover counterclockwise. Remove the dome cover. Remove the dome cover. Inserting an SD Memory Card Insert an SD memory card into the SD memory card slot with the ‘micro SD’ print facing upward. DC-D4537RXA DC-D4537HRXA Loosen the screws counterclockwise using the... -
Page 7: Installation
DC-D4537HRXA DC-D4537RXA Use the screws, anchor provided with the camera to secure the install body on a wall or a ceiling. Use the provided guide pattern to check the distance between the screws. Push the SD memory card until it disengages from the slot, and then pull it out. - Page 8 Assemble the cable rubber to the bottom cover. It is recommended to use lubricant to move the LAN cable smoothly. Pull the cable slightly and arrange the rubber as shown below. Attach the enclosed desiccant in the bottom to prevent moisture. Use the screws, anchor provided with the camera to secure the install body on a wall or a ceiling.
-
Page 9: Closing The Dome Cover
Closing the Dome Cover DC-D4537RXA Attach the dome cover to the bottom cover in a straight line.Turn the dome cover clockwise to fasten the dome cover. DC-D4537HRXA Attach the double-sided tape to the desiccant first, and attach it to the specified location inside the dome cover as shown below. - Page 10 Fasten the screws for the dome cover clockwise using the Allen wrench provided with the camera. Remove the protective film inside and outside before closing the dome cover.
-
Page 11: Specifications
Specifications Operating DC-D4537RXA -10°C ~ +50°C (14°F ~ +122°F) DC-D4537HRXA -40°C ~ +55°C (-40°F ~ +131°F) Temperature Boot Up DC-D4537RXA 0°C ~ +50˚C (32°F ~ +122˚F) DC-D4537HRXA -20°C ~ +55˚C (-4°F ~ +131˚F) Temperature Operating Humidity 0% ~ 90% Power Source , PoE(IEEE 802.3af, Class 3) Power DC-D4537RXA... - Page 12 IDIS Co., Ltd. For more information, please visit www.idisglobal.com...
