• Do not remove the SD memory card while the
system is in operation. Removing the card while
the system is in operation can cause the system
to malfunction and/or corrupt data stored on
the SD memory card.
• An SD memory card is a consumable product
with a finite service life. Prolonged use will
damage the card's memory sectors and result
in data loss or memory card failure. Test the SD
memory card regularly and replace it whenever
necessary.
• Factory Reset Switch
Restores the camera's default factory settings. For
more information, refer to the Factory Reset.
• Safety Wire Screw Hole
Use the provided screw to secure the safety wire on
to the dome cover and the bottom cover.
• O-Ring Groove
O-ring is seated in the groove for waterproof. Do NOT
remove the o-ring from the groove.
DC-D1022W / DC-D1022WR / DC-D1122W / DC-
D1122WR / DC-D1123W / DC-D1123WR / DC-
D1123WHR / DC-D1223W / DC-D1223WR / DC-
D1223WHR / DC-D1323WR / DC-D1323WHR only
• Wall/Ceiling Installation Hole
Used to screw the camera in place on a wall or a
ceiling.
• Dome Cover Screw Hole
Secures the dome cover to the camera.
• Bottom Cover
Allows you to install the camera on a wall or a ceiling.
• I/O Device Port
Used to connect I/O devices to the camera.
• Cable Access Hole
For routing cables and wires.
DC-D1022W / DC-D1022WR
If the camera is
/ DC-D1122W / DC-D1122WR / DC-D1123W /
DC-D1123WR / DC-D1123WHR / DC-D1223W /
DC-D1223WR / DC-D1223WHR / DC-D1323R / DC-
D1323WR / DC-D1323WHR
hole for waterproofing by using the enclosed cable
access hole rubber when routing cables and wires.
Waterproofing sealing is required by using silicone
etc. after blocking the cable access hole. Ask your
retailer for details.
• Vertical Rotation Adjustment Screw
Used to adjust the lens' angle and lock it in place.
• Focus Lock Ring
Locks in the focal point. Turn the ring in
counterclockwise direction to unlock and then adjust
the focus by turning the lens. Turn the ring in the
clockwise direction to lock the focus point in place.
DC-D1011 / DC-D1111 only
• Focus Lock Spring
Locks in the focal point if you adjust the focus by
turning the lens.
DC-D1212 / DC-D1212R only
Part 1 – Introduction
, block the cable access
