- Page 1 DC-D Series Installation Manual DC-D1011 / DC-D1022W / DC-D1022WR / DC-D1111 / DC-D1122 / DC-D1122R / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123 / DC-D1123R / DC-D1123V / DC-D1123VR / DC-D1123W / DC-D1123WR / DC-D1123WHR / DC-D1212R / DC-D1223 / DC-D1223R / DC-D1223V / DC-D1223VR / DC-D1223W / DC-D1223WR / DC-D1223WHR / DC-D1323R / DC-D1323WR / DC-D1323WHR...
- Page 2 Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 Before reading this manual Warning: This product emits infrared light. Do not look into the IR LED. FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
-
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
Part 1 – Introduction Product Features • Multi-streaming for high-resolution and high-quality video monitoring and simultaneous recording in real- time as well as flexible configurations for those DC-D1011 / DC-D1022W / DC-D1022WR / • Supports H.264 video compression and M-JPEG still DC-D1111 / DC-D1122 / DC-D1122R / image compression algorithms DC-D1122V / DC-D1122VR / DC-D1122W /... - Page 7 • Wide dynamic range compensation (Digital WDR) for • Supports 12 VDC and PoE (Power over Ethernet) (12 improved video quality in high-contrast situations VDC not supported by DC-D1212 / DC-D1212R • Slow shutter support for improved low-lighting video • Features a variable focus automatic iris (mega pixel capture performance lens) Not applicable to DC-D1011 / DC-D1111 /...
-
Page 8: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Ferrite Core Open Source Guide Quick Guide Allen Wrench Screws (3 ea.) -
Page 9: Overview
Part 1 – Introduction Overview Product color and design may vary depending on the model. Dome Cover Bottom DC-D1022W / DC-D1022WR / DC-D1122V / DC- D1122VR / DC-D1122W / DC-D1122WR / DC-D1123V • DC-D1022W / DC-D1022WR / DC-D1122V / DC- / DC-D1123VR / DC-D1123W / DC-D1123WR / DC- D1122VR / DC-D1122W / DC-D1122WR / DC-D1123V D1123WHR / DC-D1223V / DC-D1223VR / DC-D1223W... -
Page 10: Body
Part 1 – Introduction Body Side Cable Access Safety Wire DC-D1123 / DC-D1223 Dome Cover Screws Shield Case • Side Cable Access Hole For routing cables and wires. • Safety Wire Prevents the dome cover from falling on to the floor when detached from the camera. - Page 11 Part 1 – Introduction DC-D1123VR / DC-D1223VR / DC-D1123WR / DC- DC-D1122 D1223WR / DC-D1323WR DC-D1122R DC-D1123WHR / DC-D1223WHR / DC-D1323WHR DC-D1122V / DC-D1022W / DC-D1122W DC-D1011 / DC-D1111 / DC-D1212...
- Page 12 Part 1 – Introduction DC-D1122VR / DC-D1022WR / DC-D1122WR I/O Device Port Cable Access Hole Vertical Rotation Adjustment Screw Focus Lock Ring Focus Lock Spring & • IR LED A sensor in the middle monitors lighting levels and activates the IR LED during low-lighting conditions. DC-D1022WR / DC-D1122VR / DC-D1122WR / DC-D1123R / DC-D1123VR / DC-D1123WHR / DC- D1123WR / DC-D1212R / DC-D1122R /...
- Page 13 Part 1 – Introduction • I/O Device Port • Do not remove the SD memory card while the Used to connect I/O devices to the camera. system is in operation. Removing the card while the system is in operation can cause the system •...
-
Page 14: Factory Reset
Part 1 – Introduction Factory Reset Lens Only use the factory reset switch to restore the camera to its factory default settings. Variable Focus Automatic Iris Lens A factory reset will clear all camera settings configured by the user. Shut off the power supply, insert a straight pin into the switch hole, and press down on the reset switch. -
Page 15: I/O Device Port
Part 1 – Introduction I/O Device Port • Alarm In/Out TYPE 1 - Out: It is the BJT (Bipolar Junction Transistor) - open collector output. If the voltage and current exceed the specification limit (Max load: 50mA, Max Voltage: 30VDC), the product could be TYPE 1 damaged. - Page 16 Part 1 – Introduction • Video Out • Network Port – CVBS (Video Out) & GND (Ground): Connect Connect a network cable with an RJ-45 connector to the cable's signal line and ground line to these this port. If using a PoE switch, you can supply power ports and the connector on its opposite end to to the camera using an ethernet cable.
- Page 17 Part 1 – Introduction LED Status Indications • Check your local laws and regulations on making video or audio recordings. The user will be held LED Status Description liable for any violation of the law. (Article 25-5 of the Personal Information Protection Act: Operators Power not of image data processing devices may not operate connected...
-
Page 18: Installation
Part 1 – Introduction Installation Grounding Alarm Alarm Out (Active Low - Open Collector Output) TYPE 1 Installation of this product does not require the use of special tools. Alarm In For more information on other devices comprising the Grounding Audio overall system, refer to their respective installation Audio Out... - Page 19 Part 1 – Introduction DC-D1022W / DC-D1022WR / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123V / DC-D1123VR / DC-D1123W / DC-D1123WHR / DC-D1123WR / DC-D1223V / DC-D1223VR / DC-D1223W / DC-D1223WHR / DC- D1223WR / DC-D1323WR / DC-D1323WHR Guide Pattern Attach the enclosed desiccant beside the safety wire screw inside the dome cover to prevent moisture.
- Page 20 Part 1 – Introduction Adjust the angle of the lens. For more information, DC-D1011 / DC-D1111 / DC-D1212 / DC-D1212R refer to the Angle Adjustment. Adjust the focus and zoom levers. DC-D1011 / DC-D1111 / DC-D1212 / DC-D1212R models do not have a zoom feature. Attach the shield case to the vertical rotation adjustment screw and secure it in place.
-
Page 21: Angle Adjustment
Part 1 – Introduction Angle Adjustment Dimensions The lens can be rotated along three axes. DC-D1022W / DC-D1022WR / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123V / DC-D1123VR / DC-D1123W / DC-D1123WR / DC-D1123WHR / DC-D1223V / DC- D1223VR / DC-D1223W / DC-D1223WR / DC-D1223WHR / DC-D1323WR / DC-D1323WHR Lens Rotation... - Page 22 Part 1 – Introduction DC-D1122 / DC-D1122R / DC-D1123 / DC-D1011 / DC-D1111 / DC-D1212 / DC-D1212R DC-D1123R / DC-D1223 / DC-D1223R / DC-D1323R 132mm (5.20”) 159mm (6.26”)
-
Page 23: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio Out Audio In Alarm Out Power Sensor In Network Camera Monitor Out Power Network Remote Monitoring... -
Page 24: With Non Directip™ Nvr-Based Layout
Part 2 - Camera Connection With non DirectIP™ NVR-based Layout Sensor In Audio In Alarm Out Audio Out Network Camera Network microSD Memory Card Remote Monitoring (IDIS Solution Suite Compact or IDIS Web) Remote Recording (IDIS Solution Suite Compact) Control the camera over the network from software installed on a computer. Ideal for using the camera over the network from a remote location. -
Page 25: Part 3- Appendix
Part 3- Appendix Troubleshooting Problem Check The main unit won't turn • Check the power cable connection. • Check the power outlet. PoE switch isn't being Check the grounding status of the I/O device connected to the camera and the PoE recognized. -
Page 26: Specifications
Part 3- Appendix Specifications These product specifications may change without prior notice. Lens DC-D1022W / DC-D1022WR / DC-D1122 / Lens Type DC-D1122R / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123 / Variable Focus Automatic Iris Lens: F1.6 DC-D1123R / DC-D1123V / DC-D1123VR / DC-D1123W / DC-D1123WR / DC-D1123WHR DC-D1223 / DC-D1223R / DC-D1223V / DC-D1223VR / DC-D1223W / DC-D1223WR /... - Page 27 Part 3- Appendix Lens Iris Control / DC-D1022W / DC-D1022WR / TYPE 1 DC-D1122 / DC-D1122R / DC-D1122V / DC Auto Iris DC-D1122VR / DC-D1122W / DC-D1122WR DC-D1011 / DC-D1111 / DC-D1212 / F2.0 DC-D1212R Day & Night Filter / DC-D1022W / DC-D1022WR / TYPE 1 DC-D1122 / DC-D1122R / DC-D1122V / Supported...
- Page 28 Part 3- Appendix Lighting Sensor DC-D1022WR / DC-D1122R / DC-D1122VR / DC-D1122WR / DC-D1123R / DC-D1123VR / DC-D1123WR / DC-D1123WHR / DC-D1212R Supported / DC-D1223R / DC-D1223VR / DC-D1223WR / DC-D1223WHR / DC-D1323R / DC-D1323WR / DC-D1323WHR IR Range DC-D1022WR / DC-D1122R / DC-D1122VR / DC-D1122WR / DC-D1123R / DC-D1123VR / DC-D1123WR / DC-D1123WHR / DC-D1212R 20 m...
- Page 29 Part 3- Appendix Bitrate Control DC-D1011 / DC-D1022W / DC-D1022WR H.264 – CBR / VBR (up to 4 Mbps) DC-D1111 / DC-D1122 / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123 / DC-D1123R / DC-D1123V / H.264 – CBR / VBR (up to 8 Mbps) DC-D1123VR / DC-D1123W / DC-D1123WR / DC-D1123WHR DC-D1212R / DC-D1223 / DC-D1223R /...
- Page 30 Part 3- Appendix Connector Video Out Terminal Block Audio I/O Terminal Block (mono) TYPE 1 Alarm I/O Terminal Block TYPE 1 Ethernet Port RJ-45 Use these ports for previewing video and not monitoring video. General External Dimensions (Ø / DC-D1022W / DC-D1022WR / DC-D1122 160mm x 122mm (6.3"...
- Page 31 Part 3- Appendix Power Input / DC-D1011 / DC-D1022W / DC-D1022WR / 12V DC, TYPE 1 DC-D1111 / DC-D1122 / DC-D1122R / DC-D1122V PoE(IEEE 802.3af, Class2) / DC-D1122VR / DC-D1122W / DC-D1122WR DC-D1212 / DC-D1212R PoE(IEEE 802.3af, Class 2) Power Consumption TYPE 1 TYPE 2 Max.
- Page 32 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
