- Page 1 DC-D Series Installation Manual DC-D1223F/ DC-D1223FR Powered by...
- Page 2 Before reading this manual This is a basic installation manual for use of an IDIS netework camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 Before reading this manual Warning: This product emits infrared light. Do not look into the IR LED. FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
-
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
Part 1 – Introduction Product Features • Automatic web casting code (HTML) generation • Up to 10 simultaneous remote monitoring connections DC-D1223F/ DC-D1223FR are IP-based network • IP filtering, HTTPS, SSL, IEEE 802.1X, and configurable cameras that compress and transmit video over user authority levels for greater security ethernet. -
Page 7: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Open Source Guide Quick Guide Screws (3 ea.) Cable Access Hole Rubber... -
Page 8: Overview
Part 1 – Introduction Overview Product color and design may vary depending on the model. Dome Cover Bottom Cover Body Safety Wire Dome Cover Bottom Safety Wire Hook Ceiling Installation Hole Cable Access Hole Body Hook... -
Page 9: Body
Part 1 – Introduction Body IR LED Lens Lens Rotator DC-D1223FR Horizontal Rotator SD Card Slot Factory Reset Switch Safety Wire Screw Hole I/O Device Port Vertical Rotation Adjustment Screw Shield Case • Cable Access Hole For routing cables and wires. Block the cable access hole to prevent foreign substance from entering by using the enclosed cable access hole rubber when DC-D1223F... -
Page 10: Factory Reset
Part 1 – Introduction • IR LED Factory Reset A sensor in the middle monitors lighting levels and activates the IR LED during low-lighting conditions. Only use the factory reset switch to restore the camera DC-D1223FR only to its factory default settings. •... -
Page 11: I/O Device Port
Part 1 – Introduction I/O Device Port • Audio In/Out - Out: Connect an amplifier to this port (line out). This device does not feature a built-in audio amplifier unit and therefore requires the user to purchase a separate speaker system with a built-in amplifier. - In: Connect an audio source to this port. - Page 12 Part 1 – Introduction • Power LED LED Status Indications Indicates the system's operating status. For more LED Status Description information, refer to the LED Status Indications. If the Status LED option under System > General has Power not not been enabled, this LED will remain turned off connected regardless of the system's operating status.
-
Page 13: Installation
Part 1 – Introduction Installation Turn the camera body counterclockwise while pressing the body hook of the bottom cover to remove the camera body from the bottom cover. Installation of this product does not require the use of special tools. For more information on other devices comprising the overall system, refer to their respective installation manuals. - Page 14 Part 1 – Introduction Connect the safety wire provided with the camera to Connect the camera body to the bottom cover. the bottom cover and ceiling. It prevents the bottom Match the cable access hole position of bottom cover from falling on to the floor. cover and camera body as the following image and turn the camera body clockwise to fix it.
-
Page 15: Angle Adjustment
Part 1 – Introduction Angle Adjustment Attach the shield case to the vertical rotation adjustment screw and secure it in place. DC-D1223F only The lens can be rotated along three axes. Connect the dome cover to the camera body. Connect the safety wire provided with the camera Lens Rotation Horizontal Rotation to the bottom cover and dome cover to prevent... -
Page 16: Focus/Zoom
Part 1 – Introduction Focus/Zoom • Focus Lever Adjust the focal point by turning the lever in clockwise or counterclockwise direction. Once the Variable Focus Automatic Iris Lens focal point has been adjusted, turn the screw in clockwise direction to lock it in place. •... -
Page 17: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Alarm Out Power Sensor In Network Camera Monitor Out Power Network Remote Monitoring... -
Page 18: With Non Directip™ Nvr-Based Layout
Part 2 - Camera Connection With non DirectIP™ NVR-based Layout Sensor In Audio In Alarm Out Audio Out Network Camera Network microSD Card Remote Monitoring (IDIS Solution Suite Compact or IDIS Web) Remote Recording (IDIS Solution Suite Compact) Control the camera over the network from software installed on a computer. Ideal for using the camera over the network from a remote location. -
Page 19: Part 3 - Appendix
Part 3 - Appendix Troubleshooting Problem Check The main unit won't turn • Check the power cable connection. • Check the power outlet. PoE switch isn't being Check the grounding status of the I/O device connected to the camera and the PoE recognized. -
Page 20: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Lens Lens Type Variable Focus Automatic Iris Lens: F1.2 Focal Length 3mm - 9mm H: 123.0° (Wide) - 37.0° (Tele) Viewing Angle V: 66.0° (Wide) - 22.0° (Tele) D: 131°... - Page 21 Part 3 - Appendix Video Signal Format NTSC or PAL (selectable) Compression Algorithm H.264, M-JPEG (supports 4-stage image compression rate) Compression Resolution 352x240, 704x480, 1280x720, 1920x1080 Bitrate Control H.264 – CBR / VBR (up to 10 Mbps) Max. Transmission Rate 30 ips @ 1920x1080 + 30 ips @ 704x480 (frames per second) Multi-Stream...
- Page 22 Part 3 - Appendix General External Dimensions DC-D1223FR 155mm x 137mm (6.1" x 5.39") (Ø x H) DC-D1223F 155mm x 127mm (6.1" x 5") Packaging Dimensions (W x H x D) 203mm x 174mm x 203mm (7.99" x 6.85" x 7.99") Weight (Main Unit) 0.51 kg (1.12lb) Weight (Packaging)
- Page 23 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
