  • Page 1 Network Camera Operation Manual DC-D4517RXP Powered by...
  • Page 2 Before reading this manual This is a basic operation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
  • Page 4 Before reading this manual FCC Compliance Statement THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.

  • Page 5: Table Of Contents

    Table of Contents Part 1 - Remote Setup ........7 Remote Setup .
  • Page 6 Table of Contents Part 2 - IDIS Web ..........29 Web Live Mode .

  • Page 7: Part 1 - Remote Setup

    Part 1 - Remote Setup Remote Setup Configure basic network camera settings and all other system settings. Screen images may vary depending on the model. Launch the IDIS Discovery program and then from the main screen, select a network camera whose settings you wish to change.

  • Page 8: Quick Setup

    Part 1 - Remote Setup Quick Setup General Quick Setup allows you to set up System, Network, • Language: Select the language you wish to use for Video, and other basic settings needed for camera use. remote setup. • Name: Enter a name for the camera. (Up to 31 alphanumeric characters, including spaces) System •...

  • Page 9: Date/Time

    Part 1 - Remote Setup • Setup Date/Time - Load Default Setup: Restores all settings other than Date/Time to their factory defaults. Select Include Network Setup to load default network settings as well. For more information on network setup, refer to the Network on page 10. - Import Setup: Open a setup file and apply its settings to the camera.

  • Page 10: User/Group

    Part 1 - Remote Setup Network User/Group Change the network settings, enable FEN and security • User/Group: Change remote camera control features, and control network bandwidth use. permission settings for users and user groups. - Add Group: Add a new user group. Designate a name for the group and then specify control authorities.

  • Page 11: Ip Address

    Part 1 - Remote Setup IP Address IPv6 IPv4 • Check Use to activate IPv6. • Type: Select the type of network you are using. If this option has been changed, click Save to apply the • Type: Select the type of network you are using. If this current settings, and then restart Remote Setup.

  • Page 12: Fen

    Part 1 - Remote Setup • In WAN environment it is recommended to use the UPnP while recording images using FEN or when FEN connection is not stable. Otherwise, Select Use FEN to enable the FEN feature. surveillance and recording may not be desirable depending on your network configuration environment.

  • Page 13: Port/Qos

    Part 1 - Remote Setup Port/QoS • Use UPnP: If the camera is connected to the network via an IP router (or NAT), select this option to connect to the camera without setting up port forwarding. The IP router (or NAT) must be enabled with UPnP in order for this feature to function properly.

  • Page 14: Bandwidth Control

    Part 1 - Remote Setup Bandwidth Control • Port numbers of the remote program must be updated whenever the camera's port numbers are changed. Regulates the camera’s network bandwidth use based • ONVIF protocol may not function if using HTTPS. on network traffic fluctuations.

  • Page 15: Security

    Part 1 - Remote Setup Security IEEE 802.1X Select the IEEE 802.1X option to enable IEEE 802.1X network connection authentication. • IP Filtering: Select this option to enable IP Filtering. IP Filtering allows camera access from certain IP addresses and blocks access from others. •...

  • Page 16: Video

    Part 1 - Remote Setup Video Camera Image Sensor Configure Image Sensor settings. Configure Camera, Streaming, MAT, Privacy Masking and OSD options. • Mode: Choose resolution(16:9 for 4M and 4:3 for 5M). When changing sensor mode, some settings will be reset to default.
  • Page 17 Part 1 - Remote Setup White Balance Exposure Configure White Balance settings.Preset: Use Configure Exposure settings. preconfigured white balance settings. • AE Target Gain: Specify exposure compensation’s • Preset: Use preconfigured white balance settings. target gain. Exposure is compensated automatically based on the specified target gain.
  • Page 18 Part 1 - Remote Setup - Manual: Use the slider to select the desired shutter Day & Night speed and gain. Select the most suitable minimum Configure Day & Night settings. and maximum shutter speeds and gains for the lighting conditions in the area where the camera is located.
  • Page 19 Part 1 - Remote Setup • Switching Level: Sets up the switching level between Miscellaneous daytime and nighttime modes. For example, if the Configure Miscellaneous settings. darkness level is set to 3 and the brightness level to 5, the system switches to nighttime mode when in lighting conditions of level 3 or below and to daytime mode when in lighting conditions of level 5 or over.

  • Page 20: Streaming

    Part 1 - Remote Setup Streaming • Intelligent Codec: Analyze real-time video intelligently to minimize bitrate while maintaining frame rate and image quality. In environments where there are many video changes, image quality can be reduced. • Multi-View Streaming: Designate a specific area of the screen and stream images from that area only.

  • Page 21: Mat

    Part 1 - Remote Setup Privacy Masking Select the MAT option to use the MAT (Motion Adaptive Select Privacy Masking to set up a privacy mask over Transmission) feature during video transmission and a specific area. The section on which a privacy mask is recording.

  • Page 22: Osd

    Part 1 - Remote Setup Event Action Select OSD to indicate texts and Date/Time information. Designate event detection alert actions. • Text - Size: Select the size of the text. - Color: Select the color of the text. - Transparency: Select the transparency of the text. - Position X: Set up the X-coordinate of the text.

  • Page 23: Email

    Part 1 - Remote Setup Email Remote Callback Select Email to send out emails. Select Remote Callback to send callback messages to a remote system. • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 24: Ftp Upload

    Part 1 - Remote Setup FTP Upload Select FTP Upload to upload .jpg image of the event detected to an FTP server. - FTP Server: Enter the FTP server’s IP address (or domain name). - Upload Path: Designate the file upload path. - Port: Enter the FTP server’s port number.

  • Page 25: Event

    Part 1 - Remote Setup Event • When specifying the Upload Path or Base File Name, you cannot use special characters such as \, /, #, *, |, :, ", <, >, and ?. Configure event detection settings. • The resolution of FTP upload image can change depending on the resolution setting applied under Video >...

  • Page 26: Motion Detection

    Part 1 - Remote Setup Motion Detection • Event Action: Select a motion detection event alert action. - Send Email: Select if you wish to send an email. Select the Image Attachment option to attach a Select Motion Detection to configure motion detection .jpg image of the event detected to the email.

  • Page 27: Trip-Zone

    Part 1 - Remote Setup Trip-Zone • Daytime: Specify when daytime starts and ends. All other times will be assumed as nighttime. • Event Action: Select a motion detection event alert Select Trip-Zone to configure trip zone event settings. action. With trip zone event enabled, motion detected inside/ - Send Email: Select if you wish to send an email.

  • Page 28: Tampering

    Part 1 - Remote Setup Tampering System Event Select Tampering to configure tampering detection Select System Event and configure system event event settings. With tampering detection event enabled, settings. With system event enabled, system status will a sudden change in the video, such as due to movement be checked periodically and corresponding alerts will be of the camera or covering up of the lens, will be generated.

  • Page 29: Part 2 - Idis Web

    Part 2 - IDIS Web IDIS Web is a program that allows you to view and search video from remote locations over the Internet and can be accessed on the various web browser. System requirements for running IDIS Web are as follows: •...
  • Page 30 Part 2 - IDIS Web Enter the ID and password and click LOGIN to sign in • IDIS Web does not work with Microsoft Windows 8 metro UI. ® ® • Do not close the login window while IDIS Web is running. Switching over to Web Live or Web Search mode can cause a script error, requiring you to restart the IDIS Web program.

  • Page 31: Web Live Mode

    Part 2 - IDIS Web Web Live Mode A remote web monitoring program that allows you to monitor images from remote locales in real-time. & Press to terminate IDIS Web. Place the mouse pointer on the logo to check IDIS Web's version. TYPE 1 Displays the current time.
  • Page 32 Part 2 - IDIS Web Event status window at the bottom of the screen displays a list of events detected at remote locales. Trip zone Tampering Motion Detection Right-click on the screen to display the pop-up menu. Click to enable or disable each function.

  • Page 33: Part 3 - Appendix

    Part 3 - Appendix Setup Menu Tree (Remote Setup) Remote Setup Quick Setup System Network Video System General Date/Time User/Group Network IP Address Port/QoS Bandwidth Control Security IEEE 802.1X Video Camera Streaming Privacy Masking Event Action Email Remote Callback FTP Upload Event Motion Detection Trip zone...

  • Page 34: Index

    Part 3 - Appendix Index Quality Bitrate Control Remote Port Resolution RTSP Port Camera Name Compression Date/Time DSCP Time Sync FEN Name Use FEN FEN Server Use HTTPS Frame Rate User/Group Use UPnP IDIS Web port IPFiltering Network Bandwidth Limit ONVIF Protocol V1.0...
  • Page 35 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
