MGC Release Notes - Version 7.5
If no selection is made in the Test Options box, the tests will run one time.
Test Selection
The Test Selection box displays the tests that are available for the selected element.
All - Selects all the diagnostic tests to run. Tests vary depending on the selected MCU
component, for details, see Table 8 on page 1-66. When the MCU icon or card icon is
selected, all tests are run by default. When a card unit is selected, tests can be selected
individually.
Run button - Initiates the diagnostic tests that are selected.
Stop button - Terminates on going diagnostic tests.
IP Test Box
The IP Test box is active during the LAN test. The IP Address, Subnet Mask and Default
Gateway information must be entered. If these parameters are not entered, a pop-up box
appears when the diagnostics run the LAN test, and these fields must be entered at that
time. You can cancel the LAN test instead of entering the IP Test values.
IP Address - This is the address of the card and should be provided by the System
Administrator.
Subnet Mask - This is provided by the System Administrator.
Default Gateway - This is necessary to test the LAN Controller.
Test Results Pane
As the tests are run, the results are displayed in the Test Results table. A log report is written
containing these results.
The test categories depend on what tests are run. When the MCU icon is selected in the
Browser pane, two terms are displayed: Card and Status. When the cards or units are
selected, there are five terms displayed in this window:
Table 11: Test Selection Categories and Descriptions
Field
Card
Unit
Test
Status
Time Left
When you click on a test result (a row) in the summary table, the test details re displayed in
the Details box.
The two buttons below the Details box determine how the test results are saved in the log
report.
Save Details - Saves the details as they appear in the Details box.
Save Summary - Saves the table in the Tests Results pane to the Falcon Logs folder. The
log is named using the MCU name, Slot ID, Card name, Unit, Processor and Word
summary.
72
Description
Displays the name of the card and its serial number.
Identifies the unit on the card.
Identifies the test.
Describes whether or not the test was completed, if
it timed out, whether the test passed or failed.
Lists the time left to run on the test.
