Browser Pane
Displays the MCUs defined in the MGC Manager application. Each MCU tree can be
expanded to display the cards supported for diagnostic tests.
Main Menu
The Main Menu includes the MCU, Log and Help menus.
Table 9: Falcon Main Menu Description
Field Description
MCU •
•
•
•
•
•
Log Contains the following options:
•
•
Help Lists the following options:
•
•
Test Options Box
The Test Options box displays the modes for running tests.
Table 10: Test Options Description
Field Description
Loop Test Sets tests to repeat continuously in a loop mode.
This provides continuous testing for these
diagnostics.
Stop on Failure In this mode tests are run continuously until a failure
is detected. The diagnostic testing then stops.
Quick Test Enables running tests that do not run longer than 5
minutes. On the MGC-25, all tests run as they all
take less than 5 minutes to run.
Add MCU - To define a new MCU and add it to
the MCU list. This option is required only for
MCUs that are not currently defined in the MGC
Manager application.
Connect - Connects an MCU to the application.
Disconnect - To disconnect an MCU from the
Falcon diagnostic tool, and resets the MCU to
normal mode.
Reset MCU - To reset the MCU while remaining
in the diagnostic mode.
Remove MCU - This option removes the MCU
from the MCU list.
Properties - Lists the MCU properties: MCU
Name, IP Address, Product Type (MGC-25/50/
100), MCU Version, and the MCSM version.
Set Log File Path - Enables you to select the
folder where the log file will be saved.
Only Faults - Click this option to save only
Faults in the Log file.
About Falcon - Lists the Falcon diagnostic tool
version.
Falcon Help - Provides On Line Help for the
application.
