MGC+ Predefined IP only Entry Queues and Meeting Rooms

The MGC+ unit is shipped with two pre-defined IP Only Entry Queues and eight
predefined Meeting Rooms as follows:
•
•
The Entry Queues and Meeting Rooms are set to line rate of 384 Kbps.
Meeting Rooms 1000, 2000, 3000 and 4000 are set to Continuos Presence mode. Meeting
Rooms 5000, 6000, 7000 and 8000 are set to Video Switching mode.
Meeting Room names and Numeric IDs are identical. For example, Meeting Room 3000
has the Numeric ID 3000.
The Network Configuration wizard, which is activated when the MCU is installed in the
site for the first time, enables you to reconfigure the IP Address of the IP cards, the IP
address of the network entities and the default IP Network Service Prefix. To use the
default Entry Queues and Meeting Rooms without modifying them, define the prefix as
789.
Two Entry Queue Services (one per Entry Queue) and one default IVR Service are also
shipped with the system. When accessing an Entry Queue, the system displays a video slide
indicating the numeric IDs of the predefined Meeting Rooms that can be accessed from this
Entry Queue.
Figure 2: Entry Queue Video Slide
Entry Queue CP whose Numeric ID is 1111, and Video Session type is Continuous
Presence, is used to access Meeting Rooms 1000, 2000, 3000 and 4000.
Entry Queue VSW whose Numeric ID is 2222, and Video Session type is Video
Switching, is used to access Meeting Rooms 5000, 6000, 7000 and 8000.
Detailed Description - General
41
