Field
Description
SIP
Select this check box to indicate that SIP participants can
connect to the MCU using this service. Then select:
Specify - to manually define the SIP server.
Auto - to automatically detect the SIP server's IP
address if a DHCP or if a DNS Server is defined.
SIP Server IP
If SIP-Specify is selected, and a DHCP is not used, enter
Address or
either the IP address of the preferred SIP server or its
Name
host name (if a DNS server is used).
Domain Name
Enter the domain name to identify the SIP server in the
or IP Address
domain according to the host part in the dialed string.
3
Click OK.
A confirmation message is displayed. Click OK.
Conferencing Entities
The MGC+ unit is shipped with two Entry Queues and eight Meeting
Rooms. Different Entry Queues and Meeting Rooms are created
according to conference line rate and video session type. The Entry
Queues and Meeting Rooms are set to line rate of 384 Kbps.
Entry Queue CP whose Numeric ID is 1111, and Video Session type
is Continuous Presence, is used to access Meeting Rooms 1000,
2000, 3000 and 4000.
Entry Queue VSW whose Numeric ID is 2222, and Video Session
type is Video Switching, is used to access Meeting Rooms 5000,
6000, 7000 and 8000.
Meeting Room names and Numeric IDs are identical. For example,
Meeting Room 3000 has the Numeric ID 3000.
Meeting Rooms 1000, 2000, 3000 and 4000 are set to Continuos Presence
mode. Meeting Rooms 5000, 6000, 7000 and 8000 are set to Video
Switching mode.
www.polycom.com
8
MGC+50/100 Installation

General Safety Precautions

Follow these rules to ensure general safety:
Preparations
Obtain the following information from your network administrator:
DOC2143A
& Configuration Guide
Keep the area around the Polycom MGC+ unit clean, free of clutter
and well ventilated.
When lifting the MGC+50/100, two people at either end should lift
slowly with their feet spread out to distribute the weight. Always
keep your back straight and lift with your legs.
Decide on a suitable location for the equipment rack that will hold
the MGC+ unit and is near a grounded power outlet.
Ensure that the leveling jacks on the rack's bottom are fully
extended to the floor with the full rack's weight resting on them.
Stabilizers should be attached to a single rack . In multiple rack
installations, the racks should be coupled together. Always make
sure the rack is stable before extending a component from the rack.
Use a regulating uninterruptable power supply (UPS) to protect the
MGC+ unit from power surges and voltage spikes, and to keep it
operating in case of a power failure.
MGC+ unit, Subnet Mask and Default Gateway IP addresses
Gatekeeper IP address
DNS IP address, if applicable
SIP server IP address, if applicable
1
