8.66. MACROX -- Execute Macro

This command executes the macro corresponding to the specified number. The macro must have
been previously defined and stored in non-volatile memory via the MACROS, MACROA, and
commands. If the specified macro is empty, then an error condition of ERROR#070 will be generated.
When the MACROX executes, status messages for all of the commands in the macro will be generated
(unless acknowledgement mode
command, which is exactly the same as MACROX except that status messages are
MACROQ
suppressed.
Example Description
Q01MACROX125 Execute macro number 125.
8.67. METER -- Select which Signal is Displayed on the
Front Panel LED Meter
This command selects which signal is displayed on the front panel LED meter. The options correspond
to any of the 3 inputs, 3 outputs, or the AEC reference. The inputs are specified by the labels I1, IA,
and IB. The outputs are specified by the labels O1, OA, and OB. The AEC reference is specified by the
label R1.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description
Set front panel LED meter to display the
Q01METERI1
signal on input 1 .
Query which signal the front panel LED
Q01METER?
meter is currently set to monitor.
8.68. MGAIN -- Set Crosspoint Gains in Main Matrix or
Submatrix
This command sets or queries one or more crosspoint gains in either the main matrix or one of the EF
is turned off). The status messages can be suppressed by using the
Status Message
Status messages for all the commands in the macro
will be generated first, followed by the message:
Q01MACROX125
Status Message
Q01METERI1
Q01METERx , where x is the label
corresponding to the signal currently being
monitored. If this command was sent after
the first example given above, the response
would be Q01METERI1 .
MACROW
