Lagcmin -- Set Minimum Allowed Line Input Agc Gain; Lagcrate -- Set Ramp Rate Of Line Input Agc - Polycom Vortex EF2210 Program Manual

This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description
Set AGC maximum gain on input
Q01LAGCMAXA3
channel A to 3 dB.
Query the AGC maximum gain on
Q01LAGCMAXB?
input channel B.
8.58. LAGCMIN -- Set Minimum Allowed Line Input AGC
Gain
This command sets the minimum gain that the AGC can apply on input channels A-B. For example, if
LAGCMIN is set to -10, then the AGC for that channel can apply a minimum of -10 dB of gain to the
input signal.
This command was introduced in firmware version 2.5.0.
This command is a channel integer command. See
on this type of command. The minimum and maximum values for this command are -15 and 0,
respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description
Set AGC minimum gain on input
Q01LAGCMINA-3
channel A to -3 dB.
Query the AGC minimum gain on
Q01LAGCMINB?
input channel B.

8.59. LAGCRATE -- Set Ramp Rate of Line Input AGC

This command sets or queries the maximum rate at which the AGC can increase or decrease the gain
of the signals on input channels A-B. The ramp rate is expressed in dB/sec.
This command was introduced in firmware version 2.5.0.
Status Message
Q01LAGCMAXA3
Q01LAGCMAXBx, where x is a number
between 0 and 15, depending on the current
setting of the AGC maximum gain on input
channel B.
Section 6.3 and Section 6.2
Status Message
Q01LAGCMINA-3
Q01LAGCMINBx, where x is a number
between -15 and 0, depending on the current
setting of the AGC minimum gain on input
channel B.
for more information
