3.1.1.1 LEDs
The LED panel provides information on the status of the components (whether they are active or not) and on the net-
work activity.
Front panel LEDs
Fig. 3:
LEDs
LED
A
B
C
D
In addition to the LEDs described in the above table, the front panel also has LEDs linked to the Switch Ethernet and
SFP/SFP+ interfaces.
Ethernet interface LEDs
Fig. 4:
The table below provides information on the LEDs associated with the Switch Ethernet interface:
Switch Ethernet interface LED indicators
Teldat Edge Router Atlas-840
8-port Gigabit Ethernet Switch.
For more information on the Gigabit Ehternet switch interface, refer to:
- 8-port Ethernet switch connections
- Eth RJ45 connector
- Eth RJ45 interface
4-port 1/10 Gigabit Ethernet SFP/SFP+.
For more information on the Gigabit Ehternet switch interface, refer to:
- SFP/SFP+ connections
- Eth SFP/SFP+ connector
- Eth SFP/SFP+ interface
Definition
Power
System
Cloud Information
Reserved
on page 10
on page 18
on page 20
on page 11
on page 18
on page 20
Status Indication
Off -> Error.
On -> Power Supply OK.
Off -> System error.
On -> System initialized and operating.
Off -> No cloud configuration.
On -> Connected to the cloud. Blinking: traffic exchange with the
cloud controller.
Future purposes.
3 Components and Power Supply
