Technical Information
- No parity bit.
- No type of flow control.
Connection to the configuration port can be done through the DB9 to RJ45 connector cable, supplied together with
the device.
A.4 Connectors
A.4.1 Eth RJ45 connector
RJ45 LAN
A.4.2 Eth SFP/SFP+ connector
SFP/SFP+
18
RJ45 PIN
1
2
3
4
5
6
7
8
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
Standard SFP/SFP+ connector
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
Teldat Edge Router Atlas-840
Teldat S.A.
