Package Contents

Before continuing, verify that the VTC1020/VTC1020-PA/nROK1020 package that
you received is complete. Your package should have all the items listed in the
following table.
VTC1020
Item Part Number Name
1 6012200052X00 PE Zipper Bag #8
2 6012200053X00 PE Zipper Bag #3
(T)Terminal Blocks 3P Phoenix
3 4NCPM00302X00
Contact:1777992
Washer For SMA CONN
4 50333P0027X00
KANGYANG:TW-181
Washer For SMA CONN KANGYANG:WS6-
5 50333P0028X00
0.8(B)
6 602DCD1427X00 VTC1020 Series DVD Driver Ver:1.0
VTC1020/nROK1020 Series DVD Driver
7 602DCD1512X00
Ver:1.1
Power Cable 8Pin To 6Pin 12V DC OUT
8 603POW0234X00
SUNJET:SLNEX822910
(H)Round Head Screw W/Spring+Flat
9 50311F0100X00
Washer Long Fei:P3x6L
10 603ANT0115X00 GPS/GLONASS Antenna Unictron:SM-76G
Composite Cable For VTC1020
11 6030000225X00
ST:MD-5105158
12 6030000226X00 Multi Cable FOR VTC1020 ST:MD-5105157
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Description
PE Zipper Bag #8 170x240mm,W/China RoHS Symbol
PE Zipper Bag #3 100x70mm,W/China RoHS Symbol
(T)Terminal Blocks 3P Phoenix Contact:1777992 5.08mm Male DIP
Green
Washer For SMA CONN KANGYANG:TW-181 13x1.8mm Nylon 66
Natural
Washer For SMA CONN KANGYANG:WS6-0.8(B) 12.8x6.4x0.8mm PC
Black
VTC1020 SERIES DVD Driver VER:1.0 JCL
VTC1020/nROK1020 Series DVD Driver VER:1.1 JCL
Power Cable 8Pin To 6Pin 12V DC OUT SUNJET:SLNEX822910 ATX 2x4
PIT:3.0mm TO ATX 2x3 PIT:4.2mm UL1007 22AWG L=200mm
(H)Round Head Screw W/Spring+Flat Washer Long Fei:P3x6L P3x6 iso/
SW6x0.5 NI
GPS/GLONASS Antenna Unictron:SM-76G SMA Male L=5000mm
Composite Cable FOR VTC1020 ST:MD-5105158 DB15 TO DB9x3
L:300mm
Multi Cable For VTC1020 ST:MD-5105157 DB15 TO DB9x6 L:300mm
xiv
Qty
1
1
1
2
2
1
1
1
4
1
1
1
